Toyota Lexus RX Series(Tmmc
2022-10 → present · chassis AALH15,TALA1#,TALH17 · catalogue 523440 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 75533 — Moulding, Windshield, Outside RH | ||||
| 75535-0E090 note |
Moulding, Windshield, Outside RH
2022-10 → 2022-12
ended
|
AALH15,TALA1#,TALH17 | — | |
| 75535-0E090 |
Moulding, Windshield, Outside RH
2022-12 → —
|
AALH15,TALA1#,TALH17 | — | |
| 75535-48040 note |
Moulding, Windshield, Outside RH
2022-10 → 2022-12
ended
|
AALH15,TALA1#,TALH17 | — | |
| 75534 — Moulding, Windshield, Outside LH | ||||
| 75536-0E100 note |
Moulding, Windshield, Outside LH
2022-10 → 2022-12
ended
|
AALH15,TALA1#,TALH17 | — | |
| 75536-0E100 |
Moulding, Windshield, Outside LH
2022-12 → —
|
AALH15,TALA1#,TALH17 | — | |
| 75536-48040 note |
Moulding, Windshield, Outside LH
2022-10 → 2022-12
ended
|
AALH15,TALA1#,TALH17 | — | |
| 75545B — Clip, Windshield Outside Moulding, NO.1 | ||||
| 75545-0E020 note |
Clip, Windshield Outside Moulding, NO.1
2022-10 → —
|
AALH15,TALA1#,TALH17 | — | |
| 75545-30170 note |
Clip, Windshield Outside Moulding, NO.1
2022-10 → 2022-12
ended
|
AALH15,TALA1#,TALH17 | — | |
| 75546 — Clip, Windshield Outside Moulding | ||||
| 75561-0A010 |
Clip, Windshield Outside Moulding
2022-10 → —
|
AALH15,TALA1#,TALH17 | — | |
| 75547C — Clip, Windshield Outside Moulding, NO.3 | ||||
| 75547-0E010 |
Clip, Windshield Outside Moulding, NO.3
2024-08 → —
|
AALH15,TALA1#,TALH17 | — | |
| 75547-51021 |
Clip, Windshield Outside Moulding, NO.3
2022-10 → 2024-08
ended
|
AALH15,TALA1#,TALH17 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
