Toyota Lexus RX Series(Tmmc
2022-10 → present · chassis AALH15,TALA1#,TALH17 · catalogue 523440 · United States
Supported model
Data version 2022-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86240A — Equalizer Assy,Stereo Component | ||||
| 86240-0E010 |
Equalizer Assy,Stereo Component
2022-10 → —
|
TALA1# | — | |
| 86240-0E020 |
Equalizer Assy,Stereo Component
2022-10 → —
|
TALH17 | — | |
| 86240B — Equalizer Assy, Stereo Component, NO.2 | ||||
| 86240-0E030 |
Equalizer Assy, Stereo Component, NO.2
2022-10 → 2024-11
ended
|
TALH17 | — | |
| 86240-0E090 |
Equalizer Assy, Stereo Component, NO.2
2024-11 → —
|
TALH17 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
