Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 16100 — Pump Assy, Engine Water | ||||
| 16100-29085 |
Pump Assy, Engine Water
2005-03 → —
|
3MZFE MHU2# | — | |
| 16100G — Bolt, Stud(FOR WATER PUMP SET) | ||||
| 90116-06144 |
Bolt, Stud(FOR WATER PUMP SET)
2005-03 → —
|
3MZFE MHU2# | — | |
| 16271 — Gasket, Water Pump | ||||
| 16271-20020 |
Gasket, Water Pump
2005-03 → —
|
3MZFE MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
