Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 30900D — Plug, W/Head Straight Screw(FOR TRANSAXLE HOUSING & CASE) | ||||
| 90341-18062 note |
Plug, W/Head Straight Screw(FOR TRANSAXLE HOUSING & CASE)
2005-03 → —
|
MHU2# | — | |
| 30900E — Gasket(FOR TRANSAXLE HOUSING & CASE) | ||||
| 90430-18008 |
Gasket(FOR TRANSAXLE HOUSING & CASE)
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 32910J — Cooler Assy, Oil, NO.1 | ||||
| 32910-48070 note |
Cooler Assy, Oil, NO.1
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 35300 — Pump Assy, Oil W/Motor | ||||
| 35300-48010 note |
Pump Assy, Oil W/Motor
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 87211U — Duct, Air(FOR OIL COOLER) | ||||
| 87211-48130 note |
Duct, Air(FOR OIL COOLER)
2005-03 → 2007-05
ended
|
MHU2# | — | |
| G1271A — Hose, Motor Cooling, NO.1 | ||||
| G1271-48010 note |
Hose, Motor Cooling, NO.1
2005-03 → —
|
MHU2# | — | |
| G1272A — Hose, Motor Cooling, NO.2 | ||||
| G1272-48010 note |
Hose, Motor Cooling, NO.2
2005-03 → —
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
