Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 45201B — Ring, Shaft Snap(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2005-03 → —
|
MHU2# | — | |
| 90520-17269 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2005-03 → —
|
MHU2# | — | |
| 45210 — Shaft Assy, Steering Main | ||||
| 45210-48010 |
Shaft Assy, Steering Main
2005-03 → —
|
MHU2# | — | |
| 45220 — Shaft Assy, Steering Intermediate | ||||
| 45220-48080 |
Shaft Assy, Steering Intermediate
2005-03 → 2005-07
ended
|
MHU2# | — | |
| 45220-48160 |
Shaft Assy, Steering Intermediate
2005-07 → —
|
MHU2# | — | |
| 45250 — Column Assy, Steering | ||||
| 45250-48080 |
Column Assy, Steering
2005-03 → —
|
MHU2# | — | |
| 45253 — Cover, Steering Column Hole | ||||
| 45253-48040 |
Cover, Steering Column Hole
2005-03 → —
|
MHU2# | — | |
| 45254 — Shield, Steering Column Hole | ||||
| 45254-48040 |
Shield, Steering Column Hole
2005-03 → —
|
MHU2# | — | |
| 45271 — Clamp, Steering Column, Upper | ||||
| 45271-48010 |
Clamp, Steering Column, Upper
2005-03 → —
|
MHU2# | — | |
| 45273 — Bush, Steering Main Shaft | ||||
| 45273-12020 |
Bush, Steering Main Shaft
2005-03 → —
|
MHU2# | — | |
| 45280A — Bracket Assy, Steering Column, Upper | ||||
| 45280-48060 |
Bracket Assy, Steering Column, Upper
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 45286B — Cover, Steering Column, Upr | ||||
| 45286-48050-B0 note |
Cover, Steering Column, Upr
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 45286-48050-E0 note |
Cover, Steering Column, Upr
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 45287 — Cover, Steering Column, Lwr | ||||
| 45024-48080-B0 note |
Cover, Steering Column, Lwr
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 45024-48080-E0 note |
Cover, Steering Column, Lwr
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 45897 — Bolt, Steering Lock Set | ||||
| 45897-12020 |
Bolt, Steering Lock Set
2005-03 → —
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
