Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 47101 — Pedal Sub-assy, Brake | ||||
| 47101-48100 |
Pedal Sub-assy, Brake
2005-03 → —
|
MHU2# | — | |
| 47101A — Spring(FOR BRAKE PEDAL RETURN) | ||||
| 90507-14052 |
Spring(FOR BRAKE PEDAL RETURN)
2005-03 → —
|
MHU2# | — | |
| 47101B — Bush(FOR BRAKE PEDAL) | ||||
| 90386-13015 |
Bush(FOR BRAKE PEDAL)
2005-03 → —
|
MHU2# | — | |
| 47121 — Pad, Brake Pedal | ||||
| 47121-50020 |
Pad, Brake Pedal
2005-03 → —
|
MHU2# | — | |
| 47124 — Shaft, Brake Pedal | ||||
| 90101-10164 |
Shaft, Brake Pedal
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 47124A — Collar(FOR BRAKE PEDAL SHAFT) | ||||
| 90387-10105 |
Collar(FOR BRAKE PEDAL SHAFT)
2005-03 → —
|
MHU2# | — | |
| 47131 — Cushion(FOR STOP LAMP SWITCH) | ||||
| 90541-06036 |
Cushion(FOR STOP LAMP SWITCH)
2005-03 → —
|
MHU2# | — | |
| 47264A — Pin(FOR PUSH ROD) | ||||
| 90249-10064 |
Pin(FOR PUSH ROD)
2005-03 → —
|
MHU2# | — | |
| 55106 — Support Sub-assy, Brake Pedal | ||||
| 55106-48152 |
Support Sub-assy, Brake Pedal
2005-03 → —
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
