Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 67491A — Garnish, Front Door Lower Frame Bracket, RH | ||||
| 67491-48020 |
Garnish, Front Door Lower Frame Bracket, RH
2005-03 → —
|
MHU2# | — | |
| 67492A — Garnish, Front Door Lower Frame Bracket, LH | ||||
| 67492-48020 |
Garnish, Front Door Lower Frame Bracket, LH
2005-03 → —
|
MHU2# | — | |
| 67601 — Board Sub-assy, Front Door Trim, RH | ||||
| 67610-48321-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48321-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48331-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48351-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48351-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-A0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67610-48361-B0 note |
Board Sub-assy, Front Door Trim, RH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67601B — Clip(FOR FRONT DOOR TRIM BOARD) | ||||
| 90467-09206 note |
Clip(FOR FRONT DOOR TRIM BOARD)
2005-03 → —
|
MHU2# | — | |
| 90467-10161 note |
Clip(FOR FRONT DOOR TRIM BOARD)
2005-03 → —
|
MHU2# | — | |
| 67601L — Clip(FOR FRONT DOOR TRIM BOARD) | ||||
| 90467-07076-A0 note |
Clip(FOR FRONT DOOR TRIM BOARD)
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 90467-07076-P5 note |
Clip(FOR FRONT DOOR TRIM BOARD)
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67602 — Board Sub-assy, Front Door Trim, LH | ||||
| 67620-48341-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48341-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48351-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48371-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48371-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-A0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 67620-48381-B0 note |
Board Sub-assy, Front Door Trim, LH
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 74811E — Handle, Door Pull | ||||
| 74811-22010-A0 note |
Handle, Door Pull
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 74811-22010-B4 note |
Handle, Door Pull
2005-03 → 2007-05
ended
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
