Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 77229E — Clamp, Breather Tube | ||||
| 77229-48040 |
Clamp, Breather Tube
2005-03 → —
|
MHU2# | — | |
| 77251B — Tube, Fuel Main | ||||
| 77251-48110 |
Tube, Fuel Main
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77251-48110 |
Tube, Fuel Main
2006-08 → —
|
MHU2# | — | |
| 77261D — Tube, Fuel Tank TO Canister | ||||
| 77261-48130 |
Tube, Fuel Tank TO Canister
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77261-48130 |
Tube, Fuel Tank TO Canister
2006-08 → —
|
MHU2# | — | |
| 77281 — Bracket, Fuel Main Tube, NO.1 | ||||
| 77281-48050 |
Bracket, Fuel Main Tube, NO.1
2005-03 → —
|
MHU2# | — | |
| 77285D — Clamp, Fuel Tube, NO.1 | ||||
| 77285-48030 |
Clamp, Fuel Tube, NO.1
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77285-48030 |
Clamp, Fuel Tube, NO.1
2006-08 → —
|
MHU2# | — | |
| 77286D — Clamp, Fuel Tube, NO.2 | ||||
| 77286-48060 |
Clamp, Fuel Tube, NO.2
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77286-48060 |
Clamp, Fuel Tube, NO.2
2006-08 → —
|
MHU2# | — | |
| 77298A — Clamp, Fuel Tube, NO.4 | ||||
| 77298-48020 note |
Clamp, Fuel Tube, NO.4
2006-08 → —
|
MHU2# | — | |
| 77298-48020 note |
Clamp, Fuel Tube, NO.4
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77298-48050 note |
Clamp, Fuel Tube, NO.4
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77298-48050 note |
Clamp, Fuel Tube, NO.4
2006-08 → —
|
MHU2# | — | |
| 77298B — Clamp, Fuel Tube, NO.4 | ||||
| 77298-48060 |
Clamp, Fuel Tube, NO.4
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77298-48060 |
Clamp, Fuel Tube, NO.4
2006-08 → —
|
MHU2# | — | |
| 77299A — Clamp, Fuel Tube, NO.5 | ||||
| 77299-48010 |
Clamp, Fuel Tube, NO.5
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77299-48010 |
Clamp, Fuel Tube, NO.5
2006-08 → —
|
MHU2# | — | |
| 77411B — Support, Fuel Tube Grommet, NO.1 | ||||
| 77411-48030 |
Support, Fuel Tube Grommet, NO.1
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77411-48030 |
Support, Fuel Tube Grommet, NO.1
2006-08 → —
|
MHU2# | — | |
| 77411D — Support, Fuel Tube Grommet, NO.2 | ||||
| 77411-48040 |
Support, Fuel Tube Grommet, NO.2
2005-03 → 2006-07
ended
|
MHU2# | — | |
| 77411-48040 |
Support, Fuel Tube Grommet, NO.2
2006-08 → —
|
MHU2# | — | |
| 77748 — Pipe, Charcoal Canister, NO.2 | ||||
| 77748-48020 |
Pipe, Charcoal Canister, NO.2
2005-03 → —
|
MHU2# | — | |
| 77795 — Hose, Charcoal Canister Outlet, NO.2 | ||||
| 77795-48030 |
Hose, Charcoal Canister Outlet, NO.2
2005-03 → —
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
