Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82131 — Wire, Cowl | ||||
| 82131-48590 |
Wire, Cowl
2005-03 → —
|
MHU2# | — | |
| 82131-48600 note |
Wire, Cowl
2005-03 → —
|
MHU2# | — | |
| 82131-48610 note |
Wire, Cowl
2005-03 → —
|
MHU2# | — | |
| 82131-48590 note |
Wire, Cowl
2005-03 → —
|
MHU2# | — | |
| 82131-48600 note |
Wire, Cowl
2005-03 → —
|
MHU2# | — | |
| 82131-48610 note |
Wire, Cowl
2005-03 → —
|
MHU2# | — | |
| 82666A — Holder, Connector NO.2 | ||||
| 82666-48010 |
Holder, Connector NO.2
2005-03 → —
|
MHU2# | — | |
| 82666B — Holder, Connector NO.3 | ||||
| 82666-48150 |
Holder, Connector NO.3
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 82666C — Holder, Connector NO.4 | ||||
| 82666-48030 |
Holder, Connector NO.4
2005-03 → —
|
MHU2# | — | |
| 82666D — Holder, Connector NO.5 | ||||
| 82666-48070 |
Holder, Connector NO.5
2005-03 → —
|
MHU2# | — | |
| 82666E — Holder, Connector NO.6 | ||||
| 82666-48190 |
Holder, Connector NO.6
2005-03 → 2007-05
ended
|
MHU2# | — | |
| 82733B — Block, Passenger Side Junction | ||||
| 82733-48020 |
Block, Passenger Side Junction
2005-03 → —
|
MHU2# | — | |
| 82824K — Connector, Wiring Harness | ||||
| 82824-22080 note |
Connector, Wiring Harness
2005-03 → —
|
MHU2# | — | |
| 82824-22120 note |
Connector, Wiring Harness
2005-03 → —
|
MHU2# | — | |
| 82824-30180 note |
Connector, Wiring Harness
2005-03 → —
|
MHU2# | — | |
| 82824-30220 note |
Connector, Wiring Harness
2005-03 → —
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
