Toyota Highlander HV
2005-03 → 2007-05 · chassis MHU2# · catalogue 525410 · United States
Supported model
Data version 2007-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83100 — Meter Assy, Combination | ||||
| 83800-48560 |
Meter Assy, Combination
2005-03 → 2006-01
ended
|
MHU2# | — | |
| 83800-48561 |
Meter Assy, Combination
2006-01 → —
|
MHU2# | — | |
| 83800-48570 note |
Meter Assy, Combination
2005-03 → 2006-01
ended
|
MHU28 | — | |
| 83800-48571 note |
Meter Assy, Combination
2006-01 → —
|
MHU28 | — | |
| 83138G — Glass, Combination Meter | ||||
| 83852-48550 |
Glass, Combination Meter
2005-03 → —
|
MHU2# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
