Toyota Highlander
2019-12 → present · chassis AXUH7#,GSU7#,TXUA7# · catalogue 526430 · United States
Supported model
Data version 2023-10
Navigation & Front Monitor Display
18 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 58995G | Bracket, Console Box Mounting, NO.1 |
| 83107C | Bracket Sub-assy, Meter, NO.1 |
| 840C2 | Control Sub-assy, Integration |
| 86101H | Cord Sub-assy, Antenna |
| 86110B | Multi-display Assy |
| 86110D | Knob, Multi-display Switch |
| 86140A | Receiver Assy, Radio & Display |
| 86140B | Knob, Radio & Display Receiver Switch |
| 86203X | Wiring Sub-assy, Radio |
| 86211J | Bracket, Radio Receiver, NO.1 |
| 86211M | Bracket, Radio Receiver, NO.3 |
| 86212C | Bracket, Radio Receiver, NO.2 |
| 86212F | Bracket, Radio Receiver, NO.4 |
| 86255A | Case, Microphone, NO.1 |
| 86730A | Microphone Assy, Telephone |
| 86841 | Computer, Navigation |
| 86860 | Antenna Assy, Navigation |
| 86862 | Bracket, Navigation Antenna |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
