Toyota Lexus NX Series(JPP)
2021-10 → present · chassis AAZA2#,AAZH2#,TAZA25 · catalogue 527420 · United States
Supported model
Data version 2024-03
Deck Board & Deck Trim Cover
34 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 58331H | Bracket, Luggage Compartment Trim, NO.1 |
| 58387B | Plate, Rear Floor Finish |
| 58393E | Support, Deck Board Set |
| 58410B | Board Assy, Deck |
| 58416D | Clip, Rear Floor Board |
| 58417B | Board, Rear Floor, Rear RH |
| 58418H | Board, Rear Floor, Rear LH |
| 58460D | Striker Assy, Luggage Hold Belt |
| 58461H | Cover, Junction Block Service |
| 58470C | Handle Assy, Deck Board |
| 58491E | Plate, Battery Service Cover |
| 58495D | Plate, Rear Floor Board Cover |
| 58556D | Silencer, Rear Floor |
| 58790A | Carrier Assy, Jack |
| 58792F | Support, Jack Carrier |
| 61653C | Bracket, Deck Side Trim, RH |
| 63367D | Clip(FOR DECK FLOOR BOX) |
| 64230 | Net Assy, Room Partition |
| 64267A | Hook, Package Holder Net |
| 64714C | Cover, Deck Side Trim, RH |
| 64725F | Hook, Luggage Compartment Trim, NO.1 |
| 64730B | Panel Assy, Deck Trim Side, RH |
| 64740C | Panel Assy, Deck Trim Side, LH |
| 64766E | Bezel, Jack Cover, Lower |
| 64910J | Cover Assy, Tonneau |
| 64991 | Box, Deck Floor, Front |
| 64993 | Box, Deck Floor, Rear |
| 64995 | Box, Deck Floor, RH |
| 64997 | Box, Deck Floor, LH |
| 64997C | Clip(FOR DECK FLOOR BOX) |
| 65419 | Clip, Corner Protector |
| 66310H | Hook Assy, Rope |
| 76831D | Cover, Back Door Finish Panel, RH |
| 76832D | Cover, Back Door Finish Panel, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
