Toyota C-hr
2016-10 → present · chassis MAXH10,NGX10,50,ZGX10,ZYX1# · catalogue 528510 · United States
Supported model
Data version 2019-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 82685E — Plate, Service Plug Caution | ||||
| 82685-47090 |
Plate, Service Plug Caution
2016-10 → 2018-10
ended
|
ZYX10 | — | |
| 82685-47110 |
Plate, Service Plug Caution
2018-11 → 2019-09
ended
|
ZYX10 | — | |
| 82685-47110 |
Plate, Service Plug Caution
2019-09 → —
|
MAXH10,ZYX1# | — | |
| G9230 — Blower Assy, Battery Cooling | ||||
| G9230-47080 |
Blower Assy, Battery Cooling
2016-10 → 2019-09
ended
|
ZYX10 | — | |
| G9230-02030 |
Blower Assy, Battery Cooling
2021-09 → 2021-11
ended
|
MAXH10,ZYX10 | — | |
| G9230-47050 |
Blower Assy, Battery Cooling
2019-09 → —
|
ZYX11 | — | |
| G9230-47080 |
Blower Assy, Battery Cooling
2019-09 → 2021-08
ended
|
MAXH10,ZYX10 | — | |
| G9230-47080 |
Blower Assy, Battery Cooling
2021-12 → —
|
MAXH10,ZYX10 | — | |
| G9290A — Hose Assy, Hybrid Battery | ||||
| G9290-47030 |
Hose Assy, Hybrid Battery
2019-09 → —
|
ZYX11 | — | |
| G92DB — Seal, Hybrid Battery, NO.1 | ||||
| G92DB-47030 |
Seal, Hybrid Battery, NO.1
2019-09 → —
|
ZYX11 | — | |
| G92DH — Filter, HV Battery Intake, NO.1 | ||||
| G92DH-47070 |
Filter, HV Battery Intake, NO.1
2016-10 → 2019-09
ended
|
ZYX10 | — | |
| G92DH-47070 |
Filter, HV Battery Intake, NO.1
2019-09 → —
|
MAXH10,ZYX1# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
