Toyota Lexus NX Series(Tmmc
2022-03 → present · chassis AAZA2#,AAZH25,TAZA25 · catalogue 52E420 · United States
Supported model
Data version 2022-02
Caution Plate (EXTERIOR & INTERIOR)
20 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 11298B | Label, Emission Control Information |
| 15369A | Label, Engine Oil Information |
| 16793B | Label, Cooling Fan Information |
| 28897B | Label, Battery Caution, NO.1 |
| 28897C | Label, Battery Caution, NO.2 |
| 28898D | Label, Battery Information |
| 41992 | Label, Differential Notice |
| 41992A | Label, Differential Notice, NO.2 |
| 42666A | Label, Run Flat Tire Caution |
| 58879D | Label, Console Door Lock Caution |
| 74528J | Label, Power Back Door Caution |
| 7452A | Label, Shift Control Information |
| 74541E | Plate, Compact Spare Tire Caution |
| 74558B | Label, Battery Inspection Information |
| 74559B | Label, Fuel Information |
| 74559C | Label, Fuel Information, NO.2 |
| 74599B | Label, Driver & Passenger Airbag Information |
| 74751 | Label, Tire Pressure Information |
| 88723H | Label, Cooler Service Caution |
| C6141 | Label, Back Door OR Luggage Compartment Door Information |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
