Toyota Lexus UX250H/200
2018-10 → 2022-07 · chassis MZAA10,MZAH1# · catalogue 537410 · United States
Supported model
Data version 2023-09
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83108 — Mirror Sub-assy, Meter | ||||
| 83108-76010 note |
Mirror Sub-assy, Meter
2018-10 → 2019-03
ended
|
MZAA10,MZAH1# | — | |
| 83108-76011 note |
Mirror Sub-assy, Meter
2019-03 → 2021-08
ended
|
MZAA10,MZAH1# | — | |
| 83108-76050 note |
Mirror Sub-assy, Meter
2021-08 → 2022-07
ended
|
MZAA10,MZAH1# | — | |
| 83163 — Plate, Combination Meter Mirror, NO.1 | ||||
| 83163-76010 note |
Plate, Combination Meter Mirror, NO.1
2018-10 → 2022-07
ended
|
MZAA10,MZAH1# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
