Toyota Grand Highlander
2023-06 → present · chassis AASH1#,TASA1#,TASH15 · catalogue 556410 · United States
Supported model
Data version 2023-05
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83108 — Mirror Sub-assy, Meter | ||||
| 83108-48240 |
Mirror Sub-assy, Meter
2023-06 → 2024-05
ended
|
TASA15,TASH15 Z | — | |
| 83108-48241 |
Mirror Sub-assy, Meter
2024-06 → —
|
TASA15,TASH15 Z | — | |
| 83163 — Plate, Combination Meter Mirror, NO.1 | ||||
| 83163-48240 |
Plate, Combination Meter Mirror, NO.1
2023-06 → —
|
TASA15,TASH15 Z | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
