Toyota Lexus TX Series
2023-09 → present · chassis GYU15,TAUA1#,TAUH15 · catalogue 557410 · United States
Supported model
Data version 2024-08
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 41252 — Deflector, Dust (FOR REAR DIFFERENTIAL) | ||||
| 41252-42013 |
Deflector, Dust (FOR REAR DIFFERENTIAL)
2023-09 → —
|
TAUA15 G,M,N | — | |
| 41252-42013 |
Deflector, Dust (FOR REAR DIFFERENTIAL)
2024-12 → —
|
TAUA15 S | — | |
| 41303 — Coupling Sub-assy, Electro Magnetic Control | ||||
| 41303-48050 |
Coupling Sub-assy, Electro Magnetic Control
2023-09 → —
|
TAUA15 G,M,N | — | |
| 41303-48050 |
Coupling Sub-assy, Electro Magnetic Control
2024-12 → —
|
TAUA15 S | — | |
| 41330M — Seal, Dust (FOR TRANSMISSION COUPLING) | ||||
| 90304-94005 |
Seal, Dust (FOR TRANSMISSION COUPLING)
2023-09 → —
|
TAUA15 G,M,N | — | |
| 90304-94005 |
Seal, Dust (FOR TRANSMISSION COUPLING)
2024-12 → —
|
TAUA15 S | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
