Toyota Lexus TX Series
2023-09 → present · chassis GYU15,TAUA1#,TAUH15 · catalogue 557410 · United States
Supported model
Data version 2024-08
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 23070 — Valve Assy, Fuel Main | ||||
| 23070-25020 |
Valve Assy, Fuel Main
2024-12 → —
|
T24 TAUA15 S | — | |
| 23070-25020 |
Valve Assy, Fuel Main
2023-09 → —
|
T24 TAUH15;T24,2GR GYU15,TAUA1# G,M,N | — | |
| 23221 — Pump, Fuel | ||||
| 23221-25030 |
Pump, Fuel
2023-12 → —
|
2GR GYU15 | — | |
| 23221-25080 |
Pump, Fuel
2023-09 → —
|
T24 TAUH15;T24 TAUA1# G,M,N | — | |
| 23221-25080 |
Pump, Fuel
2024-12 → —
|
T24 TAUA15 S | — | |
| 23225A — Spacer, Fuel Pump | ||||
| 23225-31020 |
Spacer, Fuel Pump
2023-12 → —
|
2GR GYU15 | — | |
| 23225-F0010 note |
Spacer, Fuel Pump
2023-09 → —
|
T24 TAUA1# G,M,N | — | |
| 23225-F0010 |
Spacer, Fuel Pump
2023-09 → —
|
T24 TAUH15 | — | |
| 23225-F0010 note |
Spacer, Fuel Pump
2024-12 → —
|
T24 TAUA15 S | — | |
| 23226 — Ring, O(FOR FUEL PUMP) | ||||
| 90301-08019 |
Ring, O(FOR FUEL PUMP)
2023-12 → —
|
2GR GYU15 | — | |
| 90301-A0021 |
Ring, O(FOR FUEL PUMP)
2023-09 → —
|
T24 TAUH15 | — | |
| 90301-A0021 note |
Ring, O(FOR FUEL PUMP)
2024-12 → —
|
T24 TAUA15 S | — | |
| 90301-A0021 note |
Ring, O(FOR FUEL PUMP)
2023-09 → —
|
T24 TAUA1# G,M,N | — | |
| 23280P — Ring, O(FOR FUEL PRESSURE REGULATOR), NO.3 | ||||
| 90301-15024 |
Ring, O(FOR FUEL PRESSURE REGULATOR), NO.3
2023-09 → 2024-04
ended
|
T24 TAUA1# | — | |
| 90301-15024 |
Ring, O(FOR FUEL PRESSURE REGULATOR), NO.3
2023-09 → —
|
T24,2GR GYU15,TAUH15 | — | |
| 23283B — Holder, Fuel Pressure Regulator | ||||
| 23283-24010 |
Holder, Fuel Pressure Regulator
2023-12 → —
|
2GR GYU15 | — | |
| 23283-F0010 note |
Holder, Fuel Pressure Regulator
2023-09 → —
|
T24 TAUA1# G,M,N | — | |
| 23283-F0010 |
Holder, Fuel Pressure Regulator
2023-09 → —
|
T24 TAUH15 | — | |
| 23283-F0010 note |
Holder, Fuel Pressure Regulator
2024-12 → —
|
T24 TAUA15 S | — | |
| 77020A — Tube Assy, Fuel Suction W/Pump & Gage | ||||
| 77020-0E210 note |
Tube Assy, Fuel Suction W/Pump & Gage
2023-09 → —
|
TAUA1# G,M,N | — | |
| 77020-0E210 note |
Tube Assy, Fuel Suction W/Pump & Gage
2024-12 → —
|
TAUA15 S | — | |
| 77020-0E220 |
Tube Assy, Fuel Suction W/Pump & Gage
2023-09 → —
|
TAUH15 | — | |
| 77020-42300 |
Tube Assy, Fuel Suction W/Pump & Gage
2023-12 → —
|
GYU15 | — | |
| 77024A — Plate Sub-assy, Fuel Suction | ||||
| 77024-0E150 |
Plate Sub-assy, Fuel Suction
2024-12 → —
|
TAUA15 S | — | |
| 77024-0E150 |
Plate Sub-assy, Fuel Suction
2023-09 → —
|
TAUA1# G,M,N | — | |
| 77024-0E160 |
Plate Sub-assy, Fuel Suction
2023-09 → —
|
TAUH15 | — | |
| 77024-42170 |
Plate Sub-assy, Fuel Suction
2023-12 → —
|
GYU15 | — | |
| 77103 — Sub-tank Sub-assy, Fuel | ||||
| 77103-0E050 note |
Sub-tank Sub-assy, Fuel
2023-09 → —
|
TAUA1# G,M,N | — | |
| 77103-0E050 |
Sub-tank Sub-assy, Fuel
2023-09 → —
|
TAUH15 | — | |
| 77103-0E050 note |
Sub-tank Sub-assy, Fuel
2024-12 → —
|
TAUA15 S | — | |
| 77103-42120 |
Sub-tank Sub-assy, Fuel
2023-12 → —
|
GYU15 | — | |
| 77173 — Bracket, Fuel Gage | ||||
| 77173-02010 note |
Bracket, Fuel Gage
2023-09 → —
|
TAUA1# G,M,N | — | |
| 77173-02010 note |
Bracket, Fuel Gage
2024-12 → —
|
TAUA15 S | — | |
| 77173-0E021 |
Bracket, Fuel Gage
2023-09 → —
|
TAUH15 | — | |
| 77173-42020 |
Bracket, Fuel Gage
2023-12 → —
|
GYU15 | — | |
| 77175 — Support, Fuel Suction, NO.2 | ||||
| 77175-0R010 note |
Support, Fuel Suction, NO.2
2023-09 → —
|
TAUA1# G,M,N | — | |
| 77175-0R010 |
Support, Fuel Suction, NO.2
2023-09 → —
|
TAUH15 | — | |
| 77175-0R010 note |
Support, Fuel Suction, NO.2
2024-12 → —
|
TAUA15 S | — | |
| 77175-12030 |
Support, Fuel Suction, NO.2
2023-12 → —
|
GYU15 | — | |
| 77785 — Harness, Fuel Pump | ||||
| 77785-0E090 note |
Harness, Fuel Pump
2023-09 → —
|
TAUA1# G,M,N | — | |
| 77785-0E090 note |
Harness, Fuel Pump
2024-12 → —
|
TAUA15 S | — | |
| 77785-0R040 |
Harness, Fuel Pump
2023-09 → —
|
TAUH15 | — | |
| 77785-42080 |
Harness, Fuel Pump
2023-12 → —
|
GYU15 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
