Toyota Lexus TX Series
2023-09 → present · chassis GYU15,TAUA1#,TAUH15 · catalogue 557410 · United States
Supported model
Data version 2024-08
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 83108 — Mirror Sub-assy, Meter | ||||
| 83108-48240 note |
Mirror Sub-assy, Meter
2023-09 → 2024-06
ended
|
GYU15,TAUA1#,TAUH15 G,M,S | — | |
| 83108-48241 note |
Mirror Sub-assy, Meter
2024-07 → —
|
TAUH15;GYU15,TAUA1# G,M | — | |
| 83108-48241 note |
Mirror Sub-assy, Meter
2024-12 → —
|
TAUA15 S | — | |
| 83163 — Plate, Combination Meter Mirror, NO.1 | ||||
| 83163-48240 note |
Plate, Combination Meter Mirror, NO.1
2023-09 → —
|
TAUH15;GYU15,TAUA1# G,M | — | |
| 83163-48240 note |
Plate, Combination Meter Mirror, NO.1
2024-12 → —
|
TAUA15 S | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
