Toyota Lexus TX Series
2023-09 → present · chassis GYU15,TAUA1#,TAUH15 · catalogue 557410 · United States
Supported model
Data version 2024-08
Ventilation Hose
9 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 11201P | Plug(FOR CYLINDER HEAD COVER) |
| 12204 | Valve Sub-assy, Ventilation |
| 12260 | Hose Assy, Ventilation |
| 12261 | Hose, Ventilation |
| 12261A | Clip OR Clamp(FOR VENTILATION HOSE) |
| 12261B | Clip OR Clamp(FOR VENTILATION HOSE) |
| 12262 | Hose, Ventilation, NO.2 |
| 12262A | Clip(FOR VENTILATION HOSE NO.2) |
| 12266B | Hose, Ventilation Pressure Sensor, NO.1 |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
