Switch & Relay & Computer

165 part groups · 17 illustrations

Illustrations

Part groups

PNC	Description
28300	Relay Assy, Starter
28371B	Relay, Igr
28371L	Relay, Igp
28371N	Relay, Igp, NO.3
28800R	Relay, Battery Fan
28850C	Sensor Assy, Battery State
28859A	Holder, Battery Current Sensor
28911	Bracket, Integration Control Supply, NO.1
28911A	Bracket, Integration Control Supply, NO.2
28912	Supply, Integration Control
28971B	Fuse, High Voltage, NO.2
31364F	Wire, Clutch Control Solenoid
82210P	Engine Room Fusible Link
82600E	Engine Room Fuse
82600L	Luggage Room Fuse
82600N	Fuse
82610A	Block Assy, Fuse
82610C	Block Assy, Fuse
82610D	Block Assy, Fuse
82611	Cover, Fuse Block
82613	Cover, Fuse Block
82616	Puller, Fuse
82620A	Block Assy, Fusible Link
82620B	Block Assy, Fusible Link
82620E	Block Assy, Fusible Link
82620F	Block Assy, Fusible Link
82644	Computer, Semiconductor Power Integration
82660	Block Assy, Relay, Engine Room
82660B	Block Assy, Relay
82660C	Block Assy, Relay
82660D	Block Assy, Relay
82660E	Block Assy, Relay
82660F	Block Assy, Relay
82660H	Block Assy, Relay
82660J	Block Assy, Relay
82660K	Block Assy, Relay
82660M	Block Assy, Relay
82660P	Block Assy, Relay
82660Q	Block Assy, Relay
82662A	Cover, Relay Block, Upper, NO.1
82662B	Cover, Relay Block, Upper, NO.2
82662C	Cover, Relay Block, Upper, NO.3
82662D	Cover, Relay Block, Upper, NO.4
82663	Cover, Relay Block, Lower
82663A	Cover, Relay Block, Lower, NO.2
82663B	Cover, Relay Block, Lower, NO.3
82663D	Cover, Relay Block, Lower, NO.5
82666	Holder, Connector
82666H	Holder, Connector, NO.2
82666J	Holder, Connector, NO.3
82670A	Block Assy, Junction, NO.1
82672A	Cover, Junction Block
82715	Bracket,Wiring Harness Clamp
82715X	Bracket, Wiring Harness Clamp, NO.2
82715Y	Bracket, Wiring Harness Clamp, NO.3
82730G	Box Assy, Power Distribution
82740	Block Assy, Engine Room Relay
82877	Box, Computer Integration, RH
82878	Box, Computer Integration, LH
83320	Gage Assy, Fuel Sender
83520	Gage Assy,Oil Pressure Sender
83530	Switch Assy, Oil Pressure (FOR ENGINE)
84010D	Control & Panel Assy, Integration
84010H	Control & Panel Assy, Integration
84040	Master Switch Assy,Multiplex Network
84190	Switch Assy, Fold Seat
84190A	Switch Assy, Fold Seat, NO.1
84190B	Switch Assy, Fold Seat, NO.2
84190C	Switch Assy, Fold Seat, NO.3
84250A	Switch Assy, Steering Pad
84270Q	Relay, Lamp Cut
84306	Cable Sub-assy, Spiral
84319	Housing, Steering Wheel Switch
84329	Switch, Turn Signal
84330	Switch Assy, Hazard Warning Signal
84340	Switch Assy, Stop Lamp
84345	Adjuster, Stop Lamp Switch Mounting
84390B	Switch Assy, Electric Parking Brake
84523	Wire, Switch NO.1
84610G	Switch Assy, Transmission Shift, NO.1
84610H	Switch Assy, Transmission Shift, NO.2
84650	Switch Assy, Windshield Wiper
84794A	Relay, FR Wiper Deicer
84810	Switch Assy, Power Window Regulator
84810D	Switch Assy, Power Window Regulator, Rear
84840G	Switch Assy, Back Door Opener
84920C	Switch Assy, Power Seat Front, RH
84920D	Switch Assy, Power Seat Front, LH
84923	Switch, Rear Power Seat
84927	Switch, Seat Memory
84930	Switch Assy, Door Control
84930P	Switch Assy, Door Control
84931C	Switch, Back Door Control
84934B	Cover, Door Control Switch
84966A	Switch, Power Back Door Control, NO.1
84975	Switch, Trip
85530	Socket Assy, Power Outlet, NO.1
85530B	Socket Assy, Power Outlet, Rear NO.1
85530D	Socket Assy, Power Outlet, NO.2
85530E	Socket Assy, Power Outlet, NO.3
85532	Socket, Usb Charger
85532C	Socket, Usb Charger, NO.2
85532D	Socket, Usb Charger, NO.3
85535B	Cover, Power Outlet Socket, NO.1
85535E	Cover, Power Outlet Socket, NO.2
85910E	Relay, Injector
85915	Relay, Main
85924C	Relay, Igct
85924H	Relay, Igct-scene
85924K	Relay, Igct, NO.2
85925G	Relay, Ptc Heater NO.3
85934	Relay, Magnet-clutch
85940	Relay Assy, Windshield Wiper
85942	Relay, Headlamp Cleaner Control
85948	Relay, Windshield Wiper
85965	Relay, Room Lamp Control
86210D	Fuse, High Voltage
86210P	Fuse, High Voltage, NO.3
86247A	Bracket, Voltage Inverter
86247C	Bracket, Voltage Inverter, NO.2
8624A	Inverter, Voltage
86530	Relay Assy, Horn
87346K	Relay, Ptc Heater
88162	Sensor, Blind Spot Monitor, RH
88172	Sensor, Blind Spot Monitor, LH
89111	Computer, Network Gateway
89120A	Sensor, Automatic Light Control
891B0	Sensor Assy, Kick Door Control
891B1	Bracket, Kick Door Control
891B2	Sensor, Kick Door Control
89221	Computer, Multiplex Network Body
89222A	Computer, Multiplex Network Door
89227	Computer, Multiplex Tilt & Telescopic
89235A	Switch, Tilt & Telescopic
89245B	Sensor, Steering
8934C	Circuit, Second Power Supply Remote Parking
89422A	Sensor, Water Temperature
89429F	Sensor, Temperature
89430A	Computer Assy, Outer Mirror Control, LH
89430B	Computer Assy, Outer Mirror Control, RH
89439D	Bracket, Sensor, NO.1
89439J	Bracket, Sensor, NO.2
89461	Sensor, Vapor Pressure
89467B	Sensor, Air Fuel Ratio
89467C	Sensor, Air Fuel Ratio, NO.2
89467D	Sensor, Air Fuel Ratio, NO.3
89467E	Sensor, Air Fuel Ratio, NO.4
8946A	Bracket, Exhaust Sensor Clamp
8946AA	Bracket, Exhaust Sensor Clamp, NO.2
89491	Sensor, Engine Oil Level
89530C	Computer Assy, Transmission Control
89539M	Bracket, Transmission Control Computer, NO.1
89561F	Relay, Electronic Fuel Injection Main, NO.1
89561G	Relay, Electronic Fuel Injection Main, NO.2
89561H	Relay, Electronic Fuel Injection Main, NO.3
89611	Switch, Push Start
89615	Sensor, Knock Control
89710D	Computer Assy, Position Control, LH
89715	Computer, Fold Seat Control
89730A	Relay(FOR SECURITY WARNING)
89747E	Buzzer, Power Back Door Warning
89870E	Relay, Electronic Driver Unit
G1167A	Relay (FOR OIL PUMP MOTOR)
G9020E	Relay, Hybrid Water Pump
G9020J	Relay, Oil Pump

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
