Toyota Avanza/Veloz
2021-11 → present · chassis W100,W101 · catalogue 613230 · United States
Supported model
Data version 2022-11
Side Member
91 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 53354 | Gusset, Hood Reinforcement, LH |
| 53355 | Gusset, Hood Reinforcement, RH |
| 53803B | Bracket Sub-assy, Front Side Panel, RH |
| 53804B | Bracket Sub-assy, Front Side Panel, LH |
| 53821B | Bracket, Front Fender, Rear RH |
| 53822B | Bracket, Front Fender, Rear LH |
| 53825E | Protector, Front Fender, Upper RH |
| 53826A | Protector, Front Fender, Upper LH |
| 55723E | Gusset, Front Panel, RH |
| 55724B | Gusset, Front Panel, LH |
| 61023B | Pillar Sub-assy, Front Body, Inner RH |
| 61024B | Pillar Sub-assy, Front Body, Inner LH |
| 61037A | Reinforcement Sub-assy, Center Body Pillar, RH |
| 61038A | Reinforcement Sub-assy, Center Body Pillar, LH |
| 61108A | Reinforce Sub-assy, Front Body Pillar, Lower RH |
| 61109A | Reinforce Sub-assy, Front Body Pillar, Lower LH |
| 61131C | Pillar, Front Body, Outer RH |
| 61132B | Pillar, Front Body, Outer LH |
| 61203 | Rail Sub-assy, Roof Side, Inner RH |
| 61204 | Rail Sub-assy, Roof Side, Inner LH |
| 61231 | Rail, Roof Side, Inner RH |
| 61232 | Rail, Roof Side, Inner LH |
| 61235B | Bracket, Assist Grip |
| 61236C | Bracket, Assist Grip |
| 61245 | Reinforcement, Roof Side Rail, Outer RH |
| 61246 | Reinforcement, Roof Side Rail, Outer LH |
| 61247B | Reinforcement, Roof Side Rail, Inner RH |
| 61247D | Bracket, Assist Grip, RH |
| 61248B | Reinforcement, Roof Side Rail, Inner LH |
| 61248D | Bracket, Assist Grip, LH |
| 61307 | Pillar Sub-assy, Center Body, Inner RH |
| 61308 | Pillar Sub-assy, Center Body, Inner LH |
| 61311B | Pillar, Center Body, Outer RH |
| 61312B | Pillar, Center Body, Outer LH |
| 61385C | Extension, Center Body Pillar, Upper RH |
| 61386D | Extension, Center Body Pillar, Upper LH |
| 61403C | Reinforce Sub-assy, Rocker, Outer RH |
| 61404E | Reinforce Sub-assy, Rocker, Outer LH |
| 61411 | Panel, Rocker, Outer RH |
| 61412 | Panel, Rocker, Outer LH |
| 61415B | Extension, Rocker, Outer RH |
| 61416B | Extension, Rocker, Outer LH |
| 61503B | Reinforcement Sub-assy, Quarter Lock Pillar, RH |
| 61504B | Reinforcement Sub-assy, Quarter Lock Pillar, LH |
| 61602H | Panel Sub-assy, Rear Body Rear Side, LH |
| 61603E | Reinforcement Sub-assy, Quater Panel, Inner RH |
| 61604E | Reinforcement Sub-assy, Quater Panel, Inner LH |
| 61605A | Reinforcement Sub-assy, Quarter Panel, RH |
| 61606A | Reinforcement Sub-assy, Quarter Panel, LH |
| 61607H | Panel Sub-assy, Quarter Wheel House, Inner RH |
| 61608H | Panel Sub-assy, Quarter Wheel House, Inner LH |
| 61611 | Panel, Quarter, RH |
| 61612 | Panel, Quarter, LH |
| 61621F | Extension, Quarter Panel, Lower RH |
| 61622A | Extension, Quarter Panel, Lower LH |
| 61623A | Extension, Quarter Panel, Outer RH |
| 61624A | Extension, Quarter Panel, Outer LH |
| 61625F | Extension, Quarter Panel, Upper RH |
| 61626F | Extension, Quarter Panel, Upper LH |
| 61627E | Extension, Quarter Panel, Rear Lower RH |
| 61628D | Extension, Quarter Panel, Rear Lower LH |
| 61631A | Panel, Quarter Wheel House, Outer RH |
| 61632A | Panel, Quarter Wheel House, Outer LH |
| 61637A | Brace, Quarter Panel, RH |
| 61638A | Brace, Quarter Panel, LH |
| 61645B | Gusset, Quarter Wheel House, Rear RH |
| 61646B | Gusset, Quarter Wheel House, Rear LH |
| 61665J | Plate, Seat Belt Anchorage, RH |
| 61666J | Plate, Seat Belt Anchorage, LH |
| 61705 | Panel Sub-assy, Roof Side, Inner RH |
| 61706 | Panel Sub-assy, Roof Side, Inner LH |
| 61715A | Extension, Roof Side, Inner Upper RH |
| 61716A | Extension, Roof Side, Inner Upper LH |
| 61717A | Reinforcement, Quarter Panel Extension, RH |
| 61718A | Reinforcement, Quarter Panel Extension, LH |
| 61719C | Bracket, Roof Side Rail, RH |
| 61727B | Extension, Quarter Panel Reinforcement, RH |
| 61729A | Bracket, Roof Side Rail, LH |
| 61731B | Panel, Roof Side, Inner RH |
| 61732B | Panel, Roof Side, Inner LH |
| 61735A | Panel, Roof Side, Inner Rear RH |
| 61736A | Panel, Roof Side, Inner Rear LH |
| 61745A | Reinforcement, Back Door Opening, Lower RH |
| 61746A | Reinforcement, Back Door Opening, Lower LH |
| 61768B | Reinforce, Belt Anchor TO Roof Side, Inner Rear RH |
| 61769E | Reinforcement, Belt Anchor TO Quarter, Inner Lower LH |
| 62612D | Pad, Quarter Wheel House, LH |
| 65565 | Patch, Side Panel Rear End, RH |
| 65566 | Patch, Side Panel Rear End, LH |
| 68981A | Retainer, Back Door Stay, RH |
| 68982A | Retainer, Back Door Stay, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
