Toyota Sienna

1997-08 → 2003-01 · chassis MCL10 · catalogue 622410 · United States

Discontinued model Data version 2003-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Caution Plate

14 part groups · 2 illustrations

Illustrations

Figure 740284F 740284F 1997-08 → 2000-08 Figure 740789C 740789C 2000-08 → —

Part groups

PNCDescription
74515A Plate, Theft Warning
74528H Label, Power Slide Door Caution
74529 Plate, Child Proof OR Child Protector Lock Caution
74541E Plate, Compact Spare Tire Caution
74541H Plate, Body Caution
74543C Label, Rear Seat Information
74543D Plate, Rear Seat Caution, NO.1
74544C Plate, Rear Seat Caution
74544D Plate, Tire Carrier Caution
74544E Label, Rear NO.2 Seat Information
74571A Film, Label Cover
74596A Label, Side Airbag Caution
74751 Label, Tire Pressure Information
88723H Label, Cooler Service Caution
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
