Toyota Sienna
2003-01 → 2009-12 · chassis GSL2#,MCL2# · catalogue 622420 · United States
Supported model
Data version 2010-07
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 41196 — Damper, Rear Differential Dynamic | ||||
| 41196-45010 |
Damper, Rear Differential Dynamic
2003-01 → 2005-09
ended
|
MCL25 | — | |
| 41196-45010 |
Damper, Rear Differential Dynamic
2005-09 → 2006-12
ended
|
MCL25 | — | |
| 41196-45010 |
Damper, Rear Differential Dynamic
2006-12 → —
|
GSL25 | — | |
| 41653 — Stopper, Rear Differential Mount, Upper | ||||
| 41653-45020 note |
Stopper, Rear Differential Mount, Upper
2003-01 → 2005-09
ended
|
MCL25 | — | |
| 41653-45020 note |
Stopper, Rear Differential Mount, Upper
2005-09 → 2006-12
ended
|
MCL25 | — | |
| 41653-45020 note |
Stopper, Rear Differential Mount, Upper
2006-12 → —
|
GSL25 | — | |
| 41654 — Stopper, Rear Differential Mount, Lower | ||||
| 41654-45020 |
Stopper, Rear Differential Mount, Lower
2003-01 → 2005-09
ended
|
MCL25 | — | |
| 41654-45020 |
Stopper, Rear Differential Mount, Lower
2005-09 → 2006-12
ended
|
MCL25 | — | |
| 41654-45020 |
Stopper, Rear Differential Mount, Lower
2006-12 → —
|
GSL25 | — | |
| 52380 — Support, Rear Differential, NO.1 | ||||
| 52380-45030 |
Support, Rear Differential, NO.1
2003-01 → 2005-09
ended
|
MCL25 | — | |
| 52380-45030 |
Support, Rear Differential, NO.1
2005-09 → 2006-12
ended
|
MCL25 | — | |
| 52380-45030 |
Support, Rear Differential, NO.1
2006-12 → —
|
GSL25 | — | |
| 52390A — Support Assy, Differential, Rear | ||||
| 52390-45020 |
Support Assy, Differential, Rear
2003-01 → 2005-09
ended
|
MCL25 | — | |
| 52390-45020 |
Support Assy, Differential, Rear
2005-09 → 2006-12
ended
|
MCL25 | — | |
| 52390-45020 |
Support Assy, Differential, Rear
2006-12 → —
|
GSL25 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
