Toyota Sienna

2003-01 → 2009-12 · chassis GSL2#,MCL2# · catalogue 622420 · United States

Supported model Data version 2010-07
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Back Door Lock & Hinge

18 part groups · 2 illustrations

Illustrations

Figure 673015D 673015D 2003-01 → — Figure 673016G 673016G 2003-01 → —

Part groups

PNCDescription
67281F Stopper, Back Door, Lower
67282 Stopper, Back Door, NO.1
67293A Cushion, Back Door Stopper
67294B Bracket, Back Door Base Stopper
68810D Hinge Assy, Back Door, RH
68820C Hinge Assy, Back Door, LH
68905B Stay Sub-assy, Back Door, RH
68906 Stay Sub-assy, Back Door, LH
68910 Unit Assy, Power Back Door
68955C Bracket, Back Window Stay, Upper RH
68956A Bracket, Back Window Stay, Upper LH
68956B Bracket, Back Door Stay, Upper LH
68961 Bolt, Back Door Stay
69350P Lock Assy, Back Door, W/Courtesy Lamp Switch
69410C Plate Assy, Back Door Lock Striker
84260F Sensor Assy, Power Back Door, RH
84260G Sensor Assy, Power Back Door, LH
85475 Rod, Power Back Door
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
