Toyota Sienna
2003-01 → 2009-12 · chassis GSL2#,MCL2# · catalogue 622420 · United States
Supported model
Data version 2010-07
Switch & Relay & Computer
126 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 23289A | Cover, Fuel Pump Resistor |
| 28300 | Relay Assy, Starter |
| 28300D | Relay, Starter Cut |
| 28371 | Relay, Ignition, NO.1 |
| 28371C | Relay, Ignition, NO.2 |
| 28380A | Resister, Fuel Pump |
| 81980 | Flasher Assy, Turn Signal |
| 82210J | Fusible Link |
| 82241J | Pin, Short |
| 82600F | Fuse, Fuse Block |
| 82616 | Puller, Fuse |
| 82620A | Block Assy, Fusible Link |
| 82642A | Relay, Running Light |
| 82661 | Cover, Relay Block, NO.1 |
| 82672A | Cover, Junction Block |
| 82672B | Cover, Junction Block |
| 82674 | Cover, Junction Block Lower |
| 82675B | Terminal, Junction |
| 82695 | Resistor, Daytime Running Light |
| 82720 | Block Assy, Engine Room Junction |
| 82721B | Block, Engine Room Junction |
| 82730 | Block Assy, Instrument Panel Junction |
| 82824L | Pin, Short |
| 82824Z | Pin, Short |
| 83320 | Gage Assy, Fuel Sender |
| 83530 | Switch Assy, Oil Pressure (FOR ENGINE) |
| 84014B | Bulb, Printed Wire Integration Board |
| 84052 | Switch Assy, Un-lock Warning |
| 84091 | Switch Set, Satellite |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84152 | Switch, Headlamp Leveling |
| 84152B | Bulb (FOR HEADLAMP LEVELING SWITCH) |
| 84170 | Switch Assy, Interior Dome Lamp |
| 84190 | Switch Assy, Fold Seat |
| 84230 | Switch Assy, Courtesy Lamp (FOR ENGINE ROOM) |
| 84231G | Switch, Courtesy (FOR FUEL LID) |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84247A | Switch, Steering Pad, LH |
| 84250A | Switch Assy, Steering Pad |
| 84306 | Cable Sub-assy, Spiral |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84330B | Bulb, Hazard Warning Signal Switch |
| 84340 | Switch Assy, Stop Lamp |
| 84342 | Cover, Stop Lamp Switch |
| 84345 | Adjuster, Stop Lamp Switch Mounting |
| 84450 | Switch Assy, Ignition OR Starter |
| 84480 | Switch Assy, Main |
| 84480B | Bulb, Main Switch Assy |
| 84540 | Switch Assy, Neutral Start |
| 84550 | Switch Assy, Parking Brake |
| 84650D | Switch Assy, Windshield Wiper (W/RELAY, WIPER CONTROL) |
| 84746 | Switch, Tire Pressure Warning |
| 84751F | Switch, Seat Heater |
| 84751G | Switch, Seat Heater |
| 84751H | Bulb, Seat Heater Switch(FRONT) |
| 84790B | Bulb(FOR REAR WINDOW DEFOGGER SWITCH) |
| 84794A | Relay, FR Wiper Deicer |
| 84810 | Switch Assy, Power Window Regulator |
| 84810D | Switch Assy, Power Window Regulator, Rear |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84835 | Switch, Power Quarter Window |
| 84835A | Blub, Power Quarter Window Switch |
| 84840G | Switch Assy, Back Door Opener |
| 84870A | Switch Assy, Outer Mirror |
| 84920 | Switch Assy, Power Seat |
| 84921A | Knob, Power Seat Switch (FOR RECLINING) |
| 84921B | Knob, Power Seat Switch (FOR SLIDE & VERTICAL) |
| 84922B | Switch, Front Power Seat, RH |
| 84922C | Switch, Front Power Seat, LH |
| 84923 | Switch, Rear Power Seat |
| 84927 | Switch, Seat Memory |
| 84930 | Switch Assy, Door Control |
| 84962 | Switch, Power Slide Door Main |
| 84962A | Bulb (FOR POWER SLIDE DOOR MAIN SWITCH) |
| 84963 | Switch, Power Slide Door Control, NO.1 |
| 84963B | Bulb, Power Slide Control Switch, NO.1 |
| 84965 | Switch, Power Back Door Main |
| 84965A | Bulb(FOR POWER BACK DOOR MAIN SWITCH) |
| 84988F | Switch, Traction Control |
| 84988G | Bulb, Traction Control Switch |
| 85431 | Solenoid, Shift Lock |
| 85432 | Solenoid, Key Interlock |
| 85500 | Lighter Assy, Cigarette |
| 85513 | Cover, Cigarette Lighter |
| 85520 | Knob And Element Assy, Cigarette Lighter |
| 85530 | Socket Assy, Power Outlet, NO.1 |
| 85530D | Socket Assy, Power Outlet, NO.2 |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85535B | Cover, Power Outlet Socket, NO.1 |
| 85535D | Cover, Power Outlet Socket, Center |
| 85535E | Cover, Power Outlet Socket, NO.2 |
| 85912 | Relay, Defogger |
| 85913C | Relay, Heater, NO.1 |
| 85916 | Relay, Light Control |
| 85916D | Relay, Fog Lamp |
| 85916N | Relay, Taillamp |
| 85916P | Relay, Headlamp |
| 85926A | Relay, Headlamp Day Dim Light |
| 85927 | Relay, Cooling Fan |
| 85930 | Relay Assy, Power Window |
| 85930G | Relay, Acc |
| 85934 | Relay, Magnet-clutch |
| 85939 | Relay, Power Window |
| 85975 | Relay, Slide Door Closer |
| 86210A | Inverter Assy, Voltage |
| 86220A | Relay, Inverter |
| 86530 | Relay Assy, Horn |
| 87501 | Control Sub-assy, Seat Heater |
| 89111 | Computer, Network Gateway |
| 89221 | Computer, Multiplex Network Body |
| 89222A | Computer, Multiplex Network Door |
| 89224 | Computer, Multiplex Network Door, Rear RH |
| 89225 | Computer, Multiplex Network Door, Rear LH |
| 89245B | Sensor, Steering |
| 89257 | Computer, Cooling Fan |
| 89430 | Computer Assy, Outer Mirror Control |
| 89438 | Switch, Power Steering Oil Pressure |
| 89461 | Sensor, Vapor Pressure |
| 89465 | Sensor, Oxygen |
| 89467B | Sensor, Air Fuel Ratio |
| 89615 | Sensor, Knock Control |
| 89715 | Computer, Fold Seat Control |
| 89747A | Buzzer, Power Slide Door Warning, RH |
| 89747B | Buzzer, Power Slide Door Warning, LH |
| 89747C | Buzzer, Power Slide Back Door Warning |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
