Toyota Sienna
2020-11 → present · chassis AXLH4# · catalogue 622440 · United States
Supported model
Data version 2024-09
Rear Door Panel & Glass
54 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 58743D | Protector, Slide Door Panel, RH |
| 58744H | Protector, Slide Door Panel, LH |
| 65907E | Curtain Sub-assy, Rear RH |
| 65908D | Curtain Sub-assy, Rear LH |
| 65988 | Hook, Sunshade |
| 67003C | Cushion, Rear Door Panel |
| 67003H | Door Sub-assy, Slide, RH |
| 67004H | Door Sub-assy, Slide, LH |
| 67405B | Guide Sub-assy, Rear Door Window, Front RH |
| 67406B | Guide Sub-assy, Rear Door Window, Front LH |
| 67407F | Frame Sub-assy, Rear Door Window, Rear Lower RH |
| 67408F | Frame Sub-assy, Rear Door Window, Rear Lower LH |
| 67603B | Clip(FOR REAR DOOR TRIM BOARD) |
| 67603E | Clip(FOR REAR DOOR TRIM BOARD) |
| 67643 | Bracket, Rear Door Trim, NO.2 RH |
| 67644 | Bracket, Rear Door Trim, NO.2 LH |
| 67667A | Garnish, Slide Door Window, RH |
| 67668A | Garnish, Slide Door Window, LH |
| 67680B | Board Assy, Slide Door Trim, RH |
| 67690C | Board Assy, Slide Door Trim, LH |
| 67693B | Cover, Slide Door Trim, Upper LH |
| 67693C | Cover, Slide Door Trim Assy, Upper RH |
| 67693D | Cover, Slide Door Trim Assy, Lower RH |
| 67693E | Cover, Slide Door Trim Assy, Lower LH |
| 67715B | Pad, Rear Door Trim |
| 67837C | Seal, Rear Door Dust Proof |
| 67841G | Cover, Slide Door Service Hole, RH |
| 67842G | Cover, Slide Door Service Hole, LH |
| 67843A | Cover, Rear Door Service Hole, NO.2 |
| 67843D | Clip, Rear Door Service Hole |
| 67844A | Cover, Rear Door Service Hole, NO.2 LH |
| 67851E | Cover, Slide Door Service Hole, RH |
| 67852E | Cover, Slide Door Service Hole, LH |
| 67867P | Retainer, Slide Door Weatherstrip, NO.1 |
| 67867Q | Retainer, Slide Door Weatherstrip, NO.2 |
| 67867R | Retainer, Slide Door Weatherstrip, NO.3 |
| 67871E | Weatherstrip, Slide Door, NO.1 RH |
| 67872A | Weatherstrip, Slide Door, NO.1 LH |
| 68103A | Glass Sub-assy, Slide Door, RH |
| 68104A | Glass Sub-assy, Slide Door, LH |
| 68142E | Run, Slide Door Glass, RH |
| 68152E | Run, Slide Door Glass, LH |
| 68173C | Weatherstrip, Slide Door Glass, Inner RH |
| 68174C | Weatherstrip, Slide Door Glass, Inner LH |
| 68180C | Weatherstrip Assy, Rear Door Glass, Outer RH |
| 68196B | Seal, Rear Door Belt, Front RH |
| 68197A | Seal, Rear Door Belt, Front LH |
| 68198 | Seal, Rear Door Belt, Rear RH |
| 68199 | Seal, Rear Door Belt, Rear LH |
| 68230C | Weatherstrip Assy, Rear Door Glass, Outer LH |
| 74271D | Panel, Slide Door Armrest Base, Upper, RH |
| 74272D | Panel, Slide Door Armrest Base, Upper, LH |
| 84250D | Sensor Assy, Power Slide Door, RH |
| 84260J | Sensor Assy, Power Slide Door, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
