Toyota Sienna
2020-11 → present · chassis AXLH4# · catalogue 622440 · United States
Supported model
Data version 2024-09
Back Door Panel & Glass
24 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 62785F | Spacer, Back Door Glass |
| 64827B | Clip, Back Window Glass, RH |
| 67005 | Panel Sub-assy, Back Door |
| 67750 | Board Assy, Back Door Trim |
| 67750A | Clip(FOR BACK DOOR TRIM) |
| 67847 | Cover, Back Door Service Hole, RH |
| 67847J | Clip(FOR BACK DOOR SERVICE HOLE COVER) |
| 67848 | Cover, Back Door Service Hole, LH |
| 67881A | Weatherstrip, Back Door |
| 67939B | Garnish, Back Door, Center |
| 67939C | Clip(FOR BACK DOOR CENTER GARNISH) |
| 68131 | Glass, Back Door |
| 69477 | Cushion, Back Door Upper Stopper |
| 69478A | Cushion, Back Door Lower Stopper |
| 74811G | Handle, Door Pull |
| 75129C | Cushion, Rear Licence Plate |
| 75496C | Clip, Back Window Outside Moulding, RH |
| 75497B | Clip, Back Window Outside Moulding, LH |
| 75573C | Moulding, Back Window, Outside |
| 75575D | Moulding, Back Window, Lower |
| 76831A | Cover, Back Door Finish Panel, RH |
| 76832A | Cover, Back Door Finish Panel, LH |
| 76835A | Protector, Back Door Finish Panel, NO.1 |
| 89437V | Cover, Sensor |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
