Toyota Sienna
2020-11 → present · chassis AXLH4# · catalogue 622440 · United States
Supported model
Data version 2024-09
Interior Lamp
21 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 81080J | Lamp Assy, Interior Illumination, NO.1 |
| 81080K | Lamp Assy, Console Box Illumination |
| 81080V | Lamp Assy, Interior Illumination, NO.2 |
| 81080W | Lamp Assy, Interior Illumination, NO.3 |
| 81230 | Lamp Assy, Courtesy |
| 81230B | Bulb(FOR COURTESY LAMP) |
| 81240 | Lamp Assy, Room, NO.1 |
| 81240L | Bulb, Room Lamp |
| 81250D | Lamp Assy, Rear Room, RH |
| 81250G | Bulb, Rear Room Lamp, RH |
| 81269 | Switch, Map Lamp |
| 81340B | Bulb (FOR VANITY LAMP) |
| 81360K | Lamp Assy, Spot, RH |
| 81360T | Lamp Assy, Spot |
| 81360U | Bulb, Spot Lamp |
| 81361D | Lens, Spot Lamp |
| 81361E | Lens, Spot Lamp, NO.2 |
| 81362B | Lens, Interior Illumination Lamp |
| 81362C | Lens, Interior Illumination Lamp, RH |
| 81362D | Lens, Interior Illumination Lamp, LH |
| 81390C | Lamp Assy, Spot, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
