Toyota Van
1983-08 → 1988-08 · chassis YR2#,3# · catalogue 651420 · United States
Discontinued model
Data version 1988-12
Rear Floor Panel & Rear Floor Member
45 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 53265 | Plate, Battery Carrier Mounting, NO.2 |
| 53791B | Cover, Cool Air Intake Hole |
| 55152A | Bracket, 3 Way Attaching |
| 57023 | Member Sub-assy, Rear Side, RH |
| 57024 | Member Sub-assy, Rear Side, LH |
| 57068 | Member Sub-assy, Rear Floor Rear Cross, Inner |
| 57315 | Outrigger, NO.3 RH |
| 57316 | Outrigger, NO.3 LH |
| 57413 | Rail, Floor Side, Center RH |
| 57414 | Rail, Floor Side, Center LH |
| 57415 | Rail, Floor Side, Rear RH |
| 57416 | Rail, Floor Side, Rear LH |
| 57697 | Retainer, Rear Seat Cushion |
| 57781 | Pad, Dust Proof Rear Floor, NO.1 |
| 57806A | Reinforce Sub-assy, NO.1 Seat Leg, Rear NO.2 |
| 57809 | Reinforce Sub-assy, NO.1 Seat Leg, Rear NO.5 |
| 57832 | Reinforcement, Rear NO.1 Seat Leg, Front NO.2 |
| 57834 | Reinforcement, Rear NO.1 Seat Leg, Front NO.4 |
| 57835 | Reinforcement, Rear NO.1 Seat Leg, Rear NO.1 |
| 57836 | Reinforcement, Rear NO.1 Seat Leg, Rear NO.2 |
| 57841 | Reinforcement, Rear NO.2 Seat Leg, Front RH |
| 57842 | Reinforcement, Rear NO.2 Seat Leg, Front LH |
| 57845 | Reinforcement, Rear NO.2 Seat Leg, Rear RH |
| 57846 | Reinforcement, Rear NO.2 Seat Leg, Rear LH |
| 58083A | Hinge Sub-assy, Battery Service Cover, Male |
| 58137 | Bracket, Center Floor Heat Insulator, NO.4 |
| 58255B | Bracket, Parking Brake Cable Guide, NO.1 |
| 58269A | Bracket, Parking Brake Cable Guide, NO.3 |
| 58303B | Step Sub-assy, Rear Floor, RH |
| 58307 | Panel Sub-assy, Body Lower Back |
| 58309F | Balancer Sub-assy, Rear Floor |
| 58311 | Pan, Rear Floor |
| 58325D | Brace, Rear Floor Panel, RH |
| 58326D | Brace, Rear Floor Panel, LH |
| 58346A | Bracket, Rear Floor Heat Insulator, NO.2 |
| 58351A | Bracket, Spare Wheel Carrier |
| 58363B | Balancer, Rear Floor, NO.1 |
| 58367A | Bracket, Rear Floor Balancer |
| 58445C | Pad, Battery Service Hole Cover |
| 58450 | Cover Assy, Battery Service Hole |
| 58450A | Packing, Battery Service Hole Cover |
| 58689A | Weight, Rear Floor |
| 58717 | Packing, Cooler Air Inlet Cover |
| 58731B | Cap, Rear Absorber, RH |
| 58732B | Cap, Rear Absorber, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
