Toyota Previa
1990-01 → 1997-07 · chassis TCR1#,2# · catalogue 652440 · United States
Discontinued model
Data version 1998-02
Heating & Air Conditioning - Cooler Unit
63 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 82817S | Protector, Wiring Harness |
| 87050 | Radiator Assy, Air Conditioner |
| 87105C | Fan Sub-assy, Blower, Rear |
| 87107A | Unit Sub-assy, Heater Radiator |
| 87114B | Cover, Heater |
| 87138C | Resistor, Blower |
| 88306 | Motor Sub-assy, Cooler Blower, NO.1 |
| 88326A | Plate, Cover |
| 88361 | Fan, Cooler Blower, NO.1 |
| 88501 | Evaporator Sub-assy, Cooler, NO.1 |
| 88501E | Evapolator Sub-assy, Cooler (COOL BOX) |
| 88501R | Evaporator Sub-assy (REAR) |
| 88502 | Case Sub-assy, Cooling Unit |
| 88504A | Case Sub-assy, Blower |
| 88510 | Unit Assy, Cooler |
| 88510F | Holder, Fuse |
| 88515 | Valve, Cooler Expansion |
| 88515B | Valve, Rear Cooling Unit Expansion |
| 88515C | Valve, Cooling Box Expansion |
| 88520 | Box Assy, Cooling |
| 88521E | Case Sub-assy, Cooling Unit |
| 88522 | Door, Cooling Unit |
| 88536 | Bracket, Cooling Unit, NO.1 |
| 88536A | Bracket, Cooling Unit, NO.2 |
| 88536B | Bracket, Cooling Unit, NO.3 |
| 88536C | Bracket, Cooling Unit, NO.4 |
| 88539 | Hose, Cooler Unit Drain, NO.1 |
| 88539C | Hose, Cooler Unit Drain, NO.2 |
| 88539E | Hose, Cooler Unit Drain, NO.3 |
| 88539J | Hose, Drain Cooler |
| 88539K | Hose, Drain Cooler |
| 88544 | Case, Cooler Blower |
| 88550B | Motor Assy, Blower |
| 88560 | Grille Assy, Cooler Air Inlet |
| 88561E | Grille, Air Inlet |
| 88568B | Filter, Air |
| 88570 | Grille Sub-assy, Cooler Air Outlet |
| 88571C | Grille, Cooler Air Outlet |
| 88578B | Packing, Cooling Unit, NO.1 |
| 88601 | Switch Sub-assy, Cooler Control |
| 88605 | Harness Sub-assy, Cooler Wiring, NO.1 |
| 88605C | Harness Sub-assy, Cooler Wiring, NO.2 |
| 88610 | Switch Assy, Cooler Control |
| 88610S | Switch Assy, Control |
| 88625 | Thermistor, Cooler, NO.1 |
| 88625A | Thermistor, Cooler NO.2 |
| 88630 | Relay Assy, Cooler |
| 88630A | Relay Assy, Cooler |
| 88630B | Relay Assy, Cooler |
| 88630V | Relay Assy |
| 88649 | Wiring, Cooler, NO.2 |
| 88650 | Amplifier Assy, Cooler Stabilizer |
| 88650C | Amplifier Sub-assy, Airconditioner |
| 88710A | Tube Assy, Air Conditioner |
| 88710B | Tube Assy, Air Conditioner |
| 88710H | Tube & Accessory Assy, Air Conditioner |
| 88723A | Label, Cooler Service Caution |
| 88723F | Label, Cooler Service Caution |
| 88895 | Holder, Fuse |
| 88899G | Moulding, Protector |
| 88899K | Plate, Cover |
| 88899N | Plate, Cover |
| 88899P | Plate, Cover |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
