Toyota Rush
2008-11 → 2018-06 · chassis J200E,J210E · catalogue 661340 · United States
Supported model
Data version 2018-12
Back Door Panel & Glass
13 part groups · 8 illustrations
Part groups
| PNC | Description |
|---|---|
| 62785F | Spacer, Back Door Glass |
| 64780C | Panel Assy, Back Door Trim, RH |
| 64818B | Spacer, Back Door Glass, NO.1 |
| 64827A | Clip, Back Window Glass, RH |
| 67005 | Panel Sub-assy, Back Door |
| 67005A | Plug, Hole(FOR BACK DOOR PANEL) |
| 67283A | Cover, Back Door Stopper Cushion, NO.1 |
| 67395A | Protector, Back Door, Lower |
| 67847A | Cover, Back Door Service Hole |
| 67881A | Weatherstrip, Back Door |
| 67891C | Seal, Back Door |
| 68131 | Glass, Back Door |
| 68650 | Check Assy, Back Door |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
