Toyota RAV4 (JPP)
2012-12 → 2018-10 · chassis ASA4#,AVA44 · catalogue 662440 · United States
Supported model
Data version 2019-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 25611A — Pipe, Egr, NO.1 | ||||
| 25611-36011 note |
Pipe, Egr, NO.1
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25612 — Pipe, Egr, NO.2 | ||||
| 25612-36010 note |
Pipe, Egr, NO.2
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25620 — Valve Assy, Egr | ||||
| 25620-36060 note |
Valve Assy, Egr
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25620C — Hose, Water By-pass, NO.1 | ||||
| 16282-36100 note |
Hose, Water By-pass, NO.1
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25620D — Clip(FOR WATER BY-PASS HOSE, NO.1) | ||||
| 90466-21001 note |
Clip(FOR WATER BY-PASS HOSE, NO.1)
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25627 — Gasket, Egr Valve | ||||
| 25627-36010 note |
Gasket, Egr Valve
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25629A — Gasket, Egr Pipe, NO.2 | ||||
| 25629-36010 note |
Gasket, Egr Pipe, NO.2
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25634 — Gasket, Egr Pipe | ||||
| 25634-36010 note |
Gasket, Egr Pipe
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25635 — Bracket, Egr Pipe, NO.1 | ||||
| 25635-36010 note |
Bracket, Egr Pipe, NO.1
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
| 25680 — Cooler Assy, Egr | ||||
| 25680-36012 note |
Cooler Assy, Egr
2015-10 → 2018-10
ended
|
2ARFXE AVA44 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
