Toyota RAV4 (JPP)
2012-12 → 2018-10 · chassis ASA4#,AVA44 · catalogue 662440 · United States
Supported model
Data version 2019-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 77035 — Cable Sub-assy, Fuel Lid Lock Control | ||||
| 77035-42170 |
Cable Sub-assy, Fuel Lid Lock Control
2012-12 → 2013-11
ended
|
ASA4# | — | |
| 77035-42171 |
Cable Sub-assy, Fuel Lid Lock Control
2013-12 → 2015-10
ended
|
ASA4# | — | |
| 77035-42171 |
Cable Sub-assy, Fuel Lid Lock Control
2015-10 → 2018-10
ended
|
ASA4#,AVA44 | — | |
| 77306 — Lever Sub-assy, Fuel Lid Lock Open | ||||
| 77306-32020 |
Lever Sub-assy, Fuel Lid Lock Open
2012-12 → 2015-10
ended
|
ASA4# | — | |
| 77306-32020 |
Lever Sub-assy, Fuel Lid Lock Open
2015-10 → 2018-10
ended
|
ASA4#,AVA44 | — | |
| 77350 — Lid Assy, Fuel Filler Opening | ||||
| 77350-42090 |
Lid Assy, Fuel Filler Opening
2012-12 → 2015-10
ended
|
ASA4# | — | |
| 77350-42090 |
Lid Assy, Fuel Filler Opening
2015-10 → 2018-10
ended
|
ASA4#,AVA44 | — | |
| 77377 — Retainer, Fuel Filler Opening Lid Lock | ||||
| 77377-75010 |
Retainer, Fuel Filler Opening Lid Lock
2012-12 → 2015-10
ended
|
ASA4# | — | |
| 77377-75010 |
Retainer, Fuel Filler Opening Lid Lock
2015-10 → 2018-10
ended
|
ASA4#,AVA44 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
