Toyota RAV4 (JPP)
2012-12 → 2018-10 · chassis ASA4#,AVA44 · catalogue 662440 · United States
Supported model
Data version 2019-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 81210A — Lamp Assy, Fog, RH | ||||
| 81210-60180 |
Lamp Assy, Fog, RH
2012-12 → 2014-11
ended
|
ASA4# LIMD,XLE | — | |
| 81210-60200 |
Lamp Assy, Fog, RH
2014-12 → 2015-10
ended
|
ASA4# LIMD,XLE | — | |
| 81210-47010 |
Lamp Assy, Fog, RH
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD,SE,XLE | — | |
| 81210-47010 note |
Lamp Assy, Fog, RH
2015-10 → 2018-10
ended
|
AVA44 XLE | — | |
| 81210B — Bulb, Fog Lamp | ||||
| 90981-13090 note |
Bulb, Fog Lamp
2012-12 → 2015-10
ended
|
ASA4# LIMD,XLE | — | |
| 90981-13090 note |
Bulb, Fog Lamp
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD,SE,XLE | — | |
| 90981-13090 note |
Bulb, Fog Lamp
2015-10 → 2018-10
ended
|
AVA44 XLE | — | |
| 81211C — Lamp Unit, Fog Lamp, RH | ||||
| 81211-47010 |
Lamp Unit, Fog Lamp, RH
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD,SE,XLE | — | |
| 81211-47010 note |
Lamp Unit, Fog Lamp, RH
2015-10 → 2018-10
ended
|
AVA44 XLE | — | |
| 81220 — Lamp Assy, Fog, LH | ||||
| 81220-60100 |
Lamp Assy, Fog, LH
2012-12 → 2014-11
ended
|
ASA4# LIMD,XLE | — | |
| 81220-60120 |
Lamp Assy, Fog, LH
2014-12 → 2015-10
ended
|
ASA4# LIMD,XLE | — | |
| 81220-47010 |
Lamp Assy, Fog, LH
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD,SE,XLE | — | |
| 81220-47010 note |
Lamp Assy, Fog, LH
2015-10 → 2018-10
ended
|
AVA44 XLE | — | |
| 81221C — Lamp Unit, Fog Lamp, LH | ||||
| 81221-47010 |
Lamp Unit, Fog Lamp, LH
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD,SE,XLE | — | |
| 81221-47010 note |
Lamp Unit, Fog Lamp, LH
2015-10 → 2018-10
ended
|
AVA44 XLE | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
