Toyota RAV4 (JPP)
2012-12 → 2018-10 · chassis ASA4#,AVA44 · catalogue 662440 · United States
Supported model
Data version 2019-04
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 86510 — Horn Assy, High Pitched | ||||
| 86510-20280 |
Horn Assy, High Pitched
2012-12 → 2015-10
ended
|
ASA4# | — | |
| 86510-22270 note |
Horn Assy, High Pitched
2012-12 → 2015-10
ended
|
ASA4# LIMD | — | |
| 86510-20280 |
Horn Assy, High Pitched
2015-10 → 2018-10
ended
|
ASA4#,AVA44 | — | |
| 86510-22270 note |
Horn Assy, High Pitched
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD USA | — | |
| 86520 — Horn Assy, Low Pitched | ||||
| 86520-20300 |
Horn Assy, Low Pitched
2012-12 → 2015-10
ended
|
ASA4# | — | |
| 86520-22260 note |
Horn Assy, Low Pitched
2012-12 → 2015-10
ended
|
ASA4# LIMD | — | |
| 86520-20300 |
Horn Assy, Low Pitched
2015-10 → 2018-10
ended
|
ASA4#,AVA44 | — | |
| 86520-22260 note |
Horn Assy, Low Pitched
2015-10 → 2018-10
ended
|
ASA4#,AVA44 LIMD USA | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
