Toyota RAV4 EV
1997-09 → 2003-04 · chassis BEA11 · catalogue 664410 · United States
Discontinued model
Data version 2003-12
Switch & Relay & Computer
73 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 44510F | Relay(FOR REGENERATIVE BRAKING SYSTEM) |
| 81980 | Flasher Assy, Turn Signal |
| 82600G | Plate, Caution(FOR FUSE) |
| 82641 | Relay, Integration NO.1 |
| 82661 | Cover, Relay Block, NO.1 |
| 82662A | Cover, Relay Block, Upper, NO.1 |
| 82662B | Cover, Relay Block, Upper, NO.2 |
| 82662C | Cover, Relay Block, Upper, NO.3 |
| 82662D | Cover, Relay Block, Upper, NO.4 |
| 82666 | Holder, Connector |
| 82673A | Bracket, Junction Block, NO.1 |
| 83380A | Switch Assy, Pressure |
| 84052 | Switch Assy, Un-lock Warning |
| 84118 | Knob, Light Control Rheostat |
| 84119 | Rheostat, Light Control |
| 84140 | Switch Assy, Headlamp Dimmer |
| 84233 | Switch Assy, Courtesy Lamp (FOR FRONT DOOR) |
| 84234 | Switch Assy, Courtesy Lamp (FOR REAR DOOR) |
| 84235 | Switch Assy, Courtesy Lamp(FOR BACK DOOR) |
| 84306 | Cable Sub-assy, Spiral |
| 84310 | Switch Assy, Turn Signal |
| 84330 | Switch Assy, Hazard Warning Signal |
| 84330B | Bulb, Hazard Warning Signal Switch |
| 84340 | Switch Assy, Stop Lamp |
| 84450 | Switch Assy, Ignition OR Starter |
| 84550 | Switch Assy, Parking Brake |
| 84650 | Switch Assy, Windshield Wiper |
| 84660C | Switch, Cooler |
| 84660D | Bulb(FOR COOLER SWITCH) |
| 84727 | Switch, Shift Lock Control |
| 84730 | Switch Assy, Heater Blower |
| 84746 | Switch, Tire Pressure Warning |
| 84751 | Switch, Seat Heater |
| 84751B | Bulb, Seat Heater Switch |
| 84751J | Bulb, Seat Heater Switch(REAR) |
| 84751R | Switch, Seat Heater(REAR) |
| 84790 | Switch Assy, Rear Window Defogger |
| 84790B | Bulb(FOR REAR WINDOW DEFOGGER SWITCH) |
| 84794 | Switch, FR Wiper Deicer |
| 84794B | Bulb, FR Wiper Deicer Switch |
| 84794C | Cap Bulb, FR Wiper Deicer Switch |
| 84810 | Switch Assy, Power Window Regulator |
| 84810D | Switch Assy, Power Window Regulator, Rear |
| 84820 | Master Switch Assy, Power Window Regulator |
| 84841A | Switch, Fuel Lid Opener |
| 84870A | Switch Assy, Outer Mirror |
| 84930 | Switch Assy, Door Control |
| 84931B | Switch, Door Control |
| 85432 | Solenoid, Key Interlock |
| 85500 | Lighter Assy, Cigarette |
| 85513 | Cover, Cigarette Lighter |
| 85520 | Knob And Element Assy, Cigarette Lighter |
| 85533 | Lens, Cigarette Lighter Indicator |
| 85910N | Relay, EV Control Computer |
| 85910V | Relay, Seat Heater |
| 85912 | Relay, Defogger |
| 85916N | Relay, Taillamp |
| 85916P | Relay, Headlamp |
| 85930 | Relay Assy, Power Window |
| 85930P | Relay, Charge Lid Opening |
| 85933 | Computer, Shift Lock Control |
| 85940B | Relay Assy, Rear Wiper |
| 85980 | Relay Assy, Door Control |
| 85999C | Bracket, Relay, NO.3 |
| 86530 | Relay Assy, Horn |
| 87130G | Relay, Battery Blower, NO.2 |
| 88625S | Sensor, Temperature(FOR TIRE AIR PRESSURE WARNING SYSTEM) |
| 88630G | Relay Assy, Cooler |
| 88630H | Relay Assy, Cooler |
| 88630N | Relay Assy, Cooler |
| 89413A | Sensor, Transmission Revolution |
| 89654 | Relay, Power Steering |
| G4281 | Sensor, Electric Vehicle Battery Temperature |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
