Toyota 4Runner
2009-08 → present · chassis GRN28#,TRN28# · catalogue 671490 · United States
Supported model
Data version 2019-08
Moulding
68 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 51007 | Bracket Sub-assy, Side Step, NO.2 |
| 51793E | Bracket Sub-assy, Side Step, NO.1 |
| 51797B | Bracket Sub-assy, Side Step, NO.3 |
| 61429 | Reinforcement, Rocker Panel, NO.6 |
| 65333 | Stay, Floor Side Sill |
| 67857L | Protector, Rear Door Panel, RH |
| 67858E | Protector, Rear Door Panel, LH |
| 75392A | Retainer, Outside Moulding, NO.1 |
| 75393 | Retainer, Outside Moulding, NO.2 |
| 75394A | Retainer, Outside Moulding, NO.3 |
| 75395A | Clip, Outside Moulding, NO.1 |
| 75395B | Clip, Back Door Moulding, NO.1 |
| 75396 | Clip, Outside Moulding, NO.2 |
| 75396A | Clip, Outside Moulding, NO.2 |
| 75396B | Clip, Outside Moulding, NO.2 |
| 75397G | Clip, Outside Moulding, NO.3 |
| 75495C | Clip, Outside Moulding, NO.4 |
| 75533E | Moulding, Windshield, Outside |
| 75551 | Moulding, Roof Drip Side Finish, RH |
| 75552 | Moulding, Roof Drip Side Finish, LH |
| 75553 | Moulding, Roof Drip Side Finish, RH |
| 75554 | Moulding, Roof Drip Side Finish, LH |
| 75555D | Moulding, Roof Drip Side Finish, Center RH |
| 75556C | Moulding, Roof Drip Side Finish, Center LH |
| 75561A | Clip, Roof Drip Side Finish Moulding |
| 75596 | Cover, Roof Drip Side Finish Moulding Joint, RH |
| 75596D | Cover, Roof Drip Side Moulding, Front LH |
| 75601A | Moulding Sub-assy, Front Fender, RH |
| 75602A | Moulding Sub-assy, Front Fender, LH |
| 75653A | Moulding, Quarter, Outside Rear RH |
| 75654A | Moulding, Quarter, Outside Rear LH |
| 75659A | Pad, Quarter Panel Moulding, NO.1 |
| 75691A | Pad, Front Fender Outside Moulding, RH |
| 75692A | Pad, Front Fender Outside Moulding, LH |
| 75711B | Moulding, Front Door Belt, RH |
| 75712B | Moulding, Front Door Belt, LH |
| 75721A | Moulding, Rear Door Belt, RH |
| 75722A | Moulding, Rear Door Belt, LH |
| 75741 | Moulding, Rear Door, Outside RH |
| 75742 | Moulding, Rear Door, Outside LH |
| 75755C | Moulding, Front Door Window Frame, Rear RH |
| 75756C | Moulding, Front Door Window Frame, Rear LH |
| 75761A | Moulding, Rear Door Window Frame, Front RH |
| 75762A | Moulding, Rear Door Window Frame, Front LH |
| 75767A | Pad, Rear Door Moulding, NO.1 |
| 75792 | Clip, Door Window Frame Moulding |
| 75797C | Pad, Rear Door Outside Moulding, Upper |
| 75798B | Pad, Rear Door Outside Moulding, Rear |
| 75815 | Moulding, Back Door Outside, RH |
| 75816 | Moulding, Back Door Outside, LH |
| 75851 | Moulding, Rocker Panel, RH |
| 75852 | Moulding, Rocker Panel, LH |
| 75857 | Cover, Rocker Panel Moulding, RH |
| 75858 | Cover, Rocker Panel Moulding, LH |
| 75861A | Protector, Rocker Panel Moulding, NO.1 |
| 75861D | Protector, Rocker Panel Moulding, NO.1 |
| 75862A | Protector, Rocker Panel Moulding, NO.2 |
| 75862C | Protector, Rocker Panel Moulding, NO.2 |
| 75863C | Protector, Rocker Panel Moulding, NO.3 |
| 75865B | Retainer, Rocker Panel Moulding, NO.2 |
| 75866A | Retainer, Rocker Panel Moulding |
| 75867A | Clip, Rocker Panel Moulding |
| 75867C | Clip, Rocker Panel Moulding |
| 76607D | Mudguard Sub-assy, Quarter Panel, RH |
| 76608D | Mudguard Sub-assy, Quarter Panel, LH |
| 76647F | Support, Quarter Panel Front Mudguard, RH |
| 76648D | Support, Quarter Panel Front Mudguard, LH |
| 76924G | Retainer, Rocker Panel Moulding |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
