Toyota 4Runner
2024-12 → present · chassis TZNA5#,TZNH55 · catalogue 6714A0 · United States
Supported model
Data version 2024-12
Armrest & Visor
22 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 74231 | Panel, Front Armrest Base, Upper RH |
| 74232 | Panel, Front Armrest Base, Upper LH |
| 74271A | Panel, Rear Door Armrest Base, Upper RH |
| 74272A | Panel, Rear Door Armrest Base, Upper LH |
| 74310 | Visor Assy, RH |
| 74320 | Visor Assy, LH |
| 74325 | Cover, Visor Bracket |
| 74348 | Holder, Visor |
| 74610U | Grip Assy, Assist |
| 74612 | Cover, Assist Grip |
| 74614A | Plate, Assist Grip Lock |
| 74617A | Plug, Assist Grip |
| 74617B | Plug, Door Assist Grip |
| 74617C | Plug, Assist Grip |
| 74617F | Plug, Assist Grip |
| 74617G | Plug, Assist Grip, NO.3 RH |
| 74617P | Plug, Assist Grip, NO.3 LH |
| 74631C | Hook, Coat |
| 74651A | Bracket, Assist Strap |
| 74680 | Grip Assy, Pillar Assist |
| 74680B | Grip Assy, Pillar Assist, RH |
| 74680C | Grip Assy, Pillar Assist, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
