Toyota Hilux (DOUBLE CAB)
2022-08 → present · chassis GGN125,GUN12#,13#,LAN125,TGN12#,136 · catalogue 6733C0 · United States
Supported model
Data version 2023-03
Extension Housing (MTM)
7 part groups · 2 illustrations
Part groups
| PNC | Description |
|---|---|
| 33103 | Housing Sub-assy, Extension(MTM) |
| 33103J | Plug, Tight(FOR EXTENSION HOUSING) |
| 33103Q | Pin, Ring(FOR EXTENSION HOUSING) |
| 33103R | Seal, Oil(FOR MANUAL TRANSMISSION EXTENSION HOUSING) |
| 33124F | Pipe, Oil Receiver, NO.1(FOR EXTENSION HOUSING) |
| 33124G | Pipe, Oil Receiver, NO.2(FOR EXTENSION HOUSING) |
| 33146 | Deflector, Extension Housing Dust(MTM) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
