Toyota Hilux (DOUBLE CAB)
2022-08 → present · chassis GGN125,GUN12#,13#,LAN125,TGN12#,136 · catalogue 6733C0 · United States
Supported model
Data version 2023-03
Front Axle Housing & Differential
57 part groups · 5 illustrations
Part groups
| PNC | Description |
|---|---|
| 41039A | Gear Kit, Differential |
| 41101A | Carrier Sub-assy, Differential, Front |
| 41110F | Carrier Assy, Differential, Front |
| 41110M | Plug, Front Differential Filler |
| 41110N | Gasket, Front Differential Filler Plug |
| 41110P | Plug, Front Differential Drain |
| 41110Q | Gasket, Front Differential Drain Plug |
| 41110R | Plug, Breather (FOR FRONT DIFFERENTIAL) |
| 41110V | Union (FOR FRONT DIFFERENTIAL) |
| 41111D | Pin, Straight (FOR FRONT DIFFERENTIAL CARRIER) |
| 41114B | Bolt, Front Differential Bearing Cap |
| 41115F | Ring, Front Differential Oil Storage |
| 41183B | Deflector, Front Differential Side Bearing Retainer |
| 41201T | Final Gear Kit, Differential, Front |
| 41204D | Flange Sub-assy, Front Drive Pinion Companion, Front |
| 41211A | Bearing, Tapered Roller (FOR FRONT DRIVE PINION FRONT) |
| 41211B | Bearing, Tapered Roller (FOR FRONT DRIVE PINION REAR) |
| 41211L | Shim (FOR DIFFERENTIAL DRIVE PINION) |
| 41214C | Slinger, Front Differential Drive Pinion Oil |
| 41222B | Bolt (FOR FRONT DIFFERENTIAL RING GEAR SET) |
| 41231F | Spacer, Front Differential Drive Pinion Bearing |
| 41252A | Deflector, Dust (FOR FRONT DIFFERENTIAL) |
| 41302F | Case Sub-assy, Front Differential |
| 41304F | Shaft Sub-assy, Differential Side Gear, RH |
| 41304H | Ring, Hole Snap (FOR DIFFERENTIAL SIDE GEAR SHAFT) |
| 41304L | Bearing (FOR FRONT DIFFERENTIAL SIDE GEAR SHAFT RH) |
| 41304M | Ring, Shaft Snap (FOR DIFFERENTIAL SIDE GEAR SHAFT RH) |
| 41304P | Seal, Oil (FOR DIFFERENTIAL SIDE GEAR SHAFT) |
| 41306F | Shaft Sub-assy, Differential Side Gear Inter |
| 41311 | Case, Front Differential |
| 41311A | Bearing (FOR FRONT DIFFERENTIAL CASE) |
| 41311B | Washer, Plate (FOR FRONT DIFFERENTIAL CASE) |
| 41320 | Tube Assy, Front Differential |
| 41331G | Bearing, Needle Roller(FOR FRONT DIFFERENTIAL SIDE GEAR) |
| 41332B | Ring, Hole Snap (FOR DIFF SIDE GEAR INTERMEDDIATE SHAFT) |
| 41342A | Pin, Straight (FOR FRONT DIFFERENTIAL PINION SHAFT) |
| 41342F | Shaft, Front Differential Pinion, NO.1 |
| 41351F | Washer, Front Differential Pinion Thrust |
| 41361F | Washer, Front Differential Side Gear Thrust, NO.1 |
| 41400B | Actuator Assy, Differential Motor |
| 41433 | Sleeve, Differential Clutch |
| 41434 | Hub, Differential Clutch |
| 41435A | Bolt (FOR DIFFERENTIAL CLUTCH CASE SETTING) |
| 41507A | Tube, Front Differential Lock Actuator Breather, NO.2 |
| 41507B | Tube, Front Differential Lock Actuator Breather |
| 41533 | Tube, Front Differential Breather |
| 41534 | Bracket, Front Differential Breather |
| 41653B | Stopper, Differential Mount, Upper |
| 41654A | Stopper, Differential Mount, Lower |
| 41655 | Nut, Front Differential Mount, NO.1 |
| 43637C | Nut, Castle (FOR FRONT AXLE DRIVE PINION) |
| 43640G | Seal, Type T Oil (FOR FRONT AXLE DIFFERENTIAL CARRIER) |
| 52392A | Support, Front Differential, NO.1 |
| 52393A | Support, Front Differential, NO.2 |
| 52394 | Support, Front Differential, NO.3 |
| 89429H | Sensor, Temperature |
| 89429J | Gasket(FOR TEMPERATURE SENSOR) |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
