Toyota Tacoma
2004-09 → present · chassis GRN2##,3##,TRN2## · catalogue 674470 · United States
Supported model
Data version 2019-09
Cover Top
59 part groups · 4 illustrations
Part groups
| PNC | Description |
|---|---|
| 64901D | Panel Sub-assy, Tonneau Cover, Front |
| 64902D | Panel Sub-assy, Tonneau Cover, Center |
| 64903C | Panel Sub-assy, Tonneau Cover, Rear |
| 64904C | Hinge Sub-assy, Tonneau Cover, Front |
| 64905A | Hinge Sub-assy, Tonneau Cover, Rear |
| 64913B | Plate, Scuff |
| 64915B | Cap, Tonneau Cover Hinge End, Front RH |
| 64916B | Cap, Tonneau Cover Hinge End, Front LH |
| 64917B | Cap, Tonneau Cover Hinge End, Rear RH |
| 64918A | Cap, Tonneau Cover Hinge End, Rear LH |
| 64919A | Buckle, Tonneau Cover |
| 6491D | Release, Tonneau Cover, Front |
| 6491E | Release, Tonneau Cover, Center |
| 6491F | Release, Tonneau Cover, Rear |
| 64922A | Weatherstrip, Tonneau Cover, Front |
| 64923A | Weatherstrip, Tonneau Cover, Center RH |
| 64924A | Weatherstrip, Tonneau Cover, Center LH |
| 64925A | Weatherstrip, Tonneau Cover, Rear RH |
| 64926C | Weatherstrip, Tonneau Cover, Rear LH |
| 64927A | Weatherstrip, Tonneau Cover Tail Gate |
| 64933C | Pin, Tonneau Cover |
| 64934C | Bracket, Tonneau Cover Collar |
| 64937B | Cap, Tonneau Cover Holder |
| 64938B | Shim, Tonneau Cover Holder |
| 64938C | Shim, Tonneau Cover Holder(FOR FRONT HINGE) |
| 64938D | Shim, Tonneau Cover Holder(FOR REAR HINGE) |
| 64939A | Bracket, Tonneau Cover Stopper |
| 64941A | Latch, Tonneau Cover, RH |
| 64942A | Latch, Tonneau Cover, LH |
| 64943A | Latch, Tonneau Cover, Rear RH |
| 64944 | Latch, Tonneau Cover, Rear LH |
| 64945 | Cover, Tonneau Cover Latch |
| 64946A | Shim, Tonneau Cover Latch |
| 64946C | Shim, Tonneau Cover Latch, Front |
| 64946D | Shim, Tonneau Cover Latch, Rear |
| 64947A | Cover, Tonneau Cover Latch, Rear RH |
| 64948 | Cover, Tonneau Cover Latch, Rear LH |
| 64961A | Cable, Tonneau Cover Release, Front |
| 64962 | Cable, Tonneau Cover Release, Center |
| 64963A | Cable, Tonneau Cover Release, Rear |
| 64964 | Cover, Tonneau Cover Release Cable |
| 64964A | Cover, Tonneau Cover Release Cable, Center |
| 64964B | Cover, Tonneau Cover Release Cable, Rear |
| 64965 | Cover, Tonneau Cover Release Cable Extension, RH |
| 64965A | Cover, Tonneau Cover Release Cable Extension, Center RH |
| 64966 | Cover, Tonneau Cover Release Cable Extension, LH |
| 64966A | Cover, Tonneau Cover Release Cable Extension, Center LH |
| 64968A | Retainer, Tonneau Cover Release Cable |
| 64971 | Cover, Tonneau Cover Hinge, Front |
| 64972 | Cover, Tonneau Cover Hinge, Rear |
| 64973 | Protector, Tonneau Cover Hinge |
| 64974A | Plug, Tonneau Cover Hinge |
| 64975 | Seal, Tonneau Cover End Cap, NO.1 |
| 64976 | Seal, Tonneau Cover End Cap, NO.2 |
| 64982E | Bumper, Tonneau Cover Corner |
| 64983 | Bumper, Tonneau Cover Folding |
| 64984 | Spacer, Tonneau Cover Folding |
| 69391 | Striker, Top Cover Lock |
| 69415F | Cover, Top Cover Lock Striker |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
