Toyota Tacoma
2023-12 → present · chassis TZNA4#,TZNH47 · catalogue 674480 · United States
Supported model
Data version 2024-03
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 47101A — Spring(FOR BRAKE PEDAL RETURN) | ||||
| 90507-A0003 |
Spring(FOR BRAKE PEDAL RETURN)
2023-12 → —
|
TZNA4#,TZNH47 | — | |
| 47110 — Support Assy, Brake Pedal | ||||
| 47110-AK010 |
Support Assy, Brake Pedal
2023-12 → —
|
TZNA4# 8FC | — | |
| 47110-AK020 note |
Support Assy, Brake Pedal
2023-12 → —
|
TZNA40,45 DCB 8FC | — | |
| 47110-AK030 |
Support Assy, Brake Pedal
2023-12 → —
|
TZNA45 6F | — | |
| 47110-AK040 note |
Support Assy, Brake Pedal
2023-12 → —
|
TZNA45 6F | — | |
| 47110-AK050 |
Support Assy, Brake Pedal
2024-04 → —
|
TZNH47 | — | |
| 47110-AK060 note |
Support Assy, Brake Pedal
2024-04 → —
|
TZNH47 | — | |
| 47110-AK060 note |
Support Assy, Brake Pedal
2024-04 → —
|
TZNH47 | — | |
| 47121 — Pad, Brake Pedal | ||||
| 47121-34010 note |
Pad, Brake Pedal
2023-12 → —
|
TZNA40,45 DCB 8FC | — | |
| 47121-34010 note |
Pad, Brake Pedal
2024-04 → —
|
TZNH47 | — | |
| 47121-34010 note |
Pad, Brake Pedal
2024-04 → —
|
TZNH47 | — | |
| 47121-35020 |
Pad, Brake Pedal
2023-12 → —
|
TZNA45 6F | — | |
| 47121-35030 note |
Pad, Brake Pedal
2023-12 → —
|
TZNA45 6F | — | |
| 47121-62010 |
Pad, Brake Pedal
2023-12 → —
|
TZNA4#,TZNH47 ATM,CVT | — | |
| 47264A — Pin(FOR PUSH ROD) | ||||
| 90240-06028 |
Pin(FOR PUSH ROD)
2023-12 → —
|
TZNA4# | — | |
| 90240-08078 |
Pin(FOR PUSH ROD)
2024-04 → —
|
TZNH47 | — | |
| 55172A — Base, Brake Pedal Support | ||||
| 55172-04030 |
Base, Brake Pedal Support
2023-12 → —
|
TZNA4#,TZNH47 | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
