Toyota Hiace
2005-01 → 2014-02 · chassis KDH2##,LH2##,TRH2## · catalogue 711350 · United States
Supported model
Data version 2014-08
Body Stripe
39 part groups · 6 illustrations
Part groups
| PNC | Description |
|---|---|
| 75941 | Stripe, Center Pillar, RH |
| 75942 | Stripe, Center Pillar, NO.2 |
| 75945 | Stripe, Back Door |
| 75945A | Stripe, Tail Gate |
| 75946A | Stripe, Back Door, Upper RH |
| 75947A | Stripe, Back Door, Upper LH |
| 75965A | Stripe, Front Door Outside, Rear RH |
| 75966A | Stripe, Front Door Outside, Rear LH |
| 75973F | Stripe, Front Side Panel, RH |
| 75974F | Stripe, Front Side Panel, LH |
| 75975F | Stripe, Front Door Outside, Lower RH |
| 75976F | Stripe, Front Door Outside, Lower LH |
| 75977D | Stripe, Rear Door, RH |
| 75977E | Stripe, Rear Door Outside, Lower RH |
| 75978D | Stripe, Rear Door, LH |
| 75978E | Stripe, Rear Door Outside, Lower LH |
| 75983C | Stripe, Slide Door, RH |
| 75984A | Stripe, Slide Door |
| 75984C | Stripe, Slide Door, LH Upper |
| 75985 | Stripe, Front Door, RH |
| 75985A | Stripe, Side Panel, RH |
| 75986 | Stripe, Front Door, LH |
| 75986A | Stripe, Side Panel, LH |
| 75987C | Stripe, Rear Door, Outside, RH |
| 75987D | Stripe, Rear Door, Outside, RH |
| 75988C | Stripe, Rear Door, Outside LH |
| 75988D | Stripe, Rear Door Outside, LH |
| 75991A | Stripe, Quarter, RH |
| 75991B | Stripe, Quarter, RH |
| 75991D | Stripe, Quarter, Front RH |
| 75992 | Stripe, Quarter, LH NO.1 |
| 75992A | Stripe, Quarter, LH |
| 75992D | Stripe, Quarter, Front LH |
| 75993A | Stripe, Quarter, Rear RH |
| 75994B | Strip, Quarter, Rear LH |
| 75996E | Stripe, Quarter, Front Lower RH |
| 75997F | Stripe, Quarter, Front Lower LH |
| 75998E | Stripe, Quarter Rear Lower, RH |
| 75999E | Stripe, Quarter Rear Lower, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
