Toyota Land Cruiser
1990-01 → 2008-08 · chassis FJ,FZJ,HDJ,HJ,HZJ,KZJ,LJ,PZJ,RJ7# · catalogue 781330 · United States
Discontinued model
Data version 2014-05
Back Door Panel & Glass
43 part groups · 3 illustrations
Part groups
| PNC | Description |
|---|---|
| 62335D | Cover, Rear Door Opening Trim, RH |
| 62336A | Cover, Rear Door Opening Trim, LH |
| 62571F | Garnish, Roof Side Inner Lower RH |
| 62583D | Cover, Ouarter Pillar, Upper RH |
| 62638D | Garnish, Quarter Pillar, RH |
| 64780C | Panel Assy, Back Door Trim, RH |
| 64790C | Panel Assy, Back Door Trim, LH |
| 64805 | Trim Sub-assy, Back Door Opening |
| 67005D | Panel Sub-assy, Back Door, RH |
| 67006A | Panel Sub-assy, Back Door, LH |
| 67751A | Clip(FOR BACK DOOR TRIM BOARD) |
| 67847 | Cover, Back Door Service Hole, RH |
| 67848 | Cover, Back Door Service Hole, LH |
| 67881A | Weatherstrip, Back Door |
| 67881B | Weatherstrip, Back Door, Upper RH |
| 67882B | Weatherstrip, Back Door, Upper LH |
| 67882C | Weatherstrip, Back Door, NO.2 |
| 67883C | Weatherstrip, Back Door, Lower RH |
| 67884C | Weatherstrip, Back Door, Lower LH |
| 67891A | Seal, Back Door |
| 67891B | Clip(FOR BACK DOOR SEAL) |
| 68131C | Glass, Back Door, RH |
| 68131D | Glass, Back Door, LH |
| 68285 | Moulding, Back Door Frame, RH |
| 68286 | Moulding, Back Door Frame, LH |
| 68291D | Weatherstrip, Back Door Glass, RH |
| 68291E | Weatherstrip, Back Door Glass, LH |
| 68299 | Spacer, Back Door Weatherstrip |
| 68607F | Frame Sub-assy, Back Door Window, RH |
| 68608F | Frame Sub-assy, Back Door Window, LH |
| 68611 | Base, Back Door Check, RH |
| 68612 | Base, Back Door Check, LH |
| 68617B | Pin, Back Door Check |
| 68617C | Pin, Door Check, LH |
| 68645 | Cover, Back Door Window Frame, A |
| 68646 | Cover, Back Door Window Frame, B |
| 68647 | Cover, Back Door Window Frame, C |
| 68648 | Cover, Back Door Window Frame, D |
| 68650C | Check Assy, Back Door, RH |
| 68660 | Check Assy, Back Door, LH |
| 68695 | Pad, Back Door Window Frame |
| 68699 | Spacer, Back Door Window Frame |
| 69717 | Cover, Back Door Lock Control Link |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
