Toyota Land Cruiser
1990-01 → 2008-08 · chassis FJ,FZJ,HDJ,HJ,HZJ,KZJ,LJ,PZJ,RJ7# · catalogue 781330 · United States
Discontinued model
Data version 2014-05
Accelerator Link
37 part groups · 11 illustrations
Part groups
| PNC | Description |
|---|---|
| 78010B | Spring, Torsion (FOR ACCELERATOR LINK) |
| 78024 | Bracket Sub-assy, Accelerator Control Cable |
| 78100 | Link Assy, Accelerator |
| 78103 | Rod Sub-assy, Accelerator Connecting, NO.1 |
| 78104 | Rod Sub-assy, Accelerator Connecting, NO.2 |
| 78110C | Bush (FOR ACCELERATOR PEDAL ROD) |
| 78111 | Pedal, Accelerator |
| 78111A | Spring (FOR ACCELERATOR PEDAL) |
| 78111E | Pad, Accelerator Pedal |
| 78117 | Cushion (FOR ACCELERATOR ROD) |
| 78118B | Stopper, Accelerator Pedal |
| 78120G | Rod Assy, Accelerator Pedal |
| 78134 | End, Accelerator Connecting Rod |
| 78160A | Bellcrank Assy, Accel Control W/Bracket |
| 78166 | Bracket, Accel Control NO.2 Bellcrank |
| 78169 | Hanger, Accelerator Spring |
| 78169A | Spring, Clamp, NO.4 |
| 78180P | Cable Assy, Accelerator Control |
| 78183B | Clamp, Accelerator Control Cable |
| 78184B | Bracket, Accelerator Control Cable |
| 78185A | Clamp, Accelerator Control Cable, NO.2 |
| 78185B | Bracket, Accel Control NO.6 Rod, Rear |
| 78186 | Support, Accelerator Control Cable, NO.1 |
| 78187A | Clamp, Accelerator Control Cable, NO.4 |
| 78189 | Bolt, Accelerator Pedal Stopper |
| 78191A | Clamp (FOR ACCELERATOR WIRE SET) |
| 78193A | Support, Accelerator Control Cable, NO.3 |
| 78194A | Support, Accelerator Control Cable, NO.4 |
| 78195 | Bracket, Accelerator Link |
| 78197 | Clip, Accelerator Joint Ball |
| 78310 | Cable Assy, Choke |
| 78310C | Clip (FOR CHOKE CABLE) |
| 78311 | Knob, Choke Control Cable |
| 78410 | Cable Assy, Throttle Control |
| 78410D | Nut, Throttle |
| 78411A | Knob, Throttle Control Cable |
| 78472 | Support, Throttle Control Cable |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
