Toyota Land Cruiser

1990-01 → 2008-08 · chassis FJ,FZJ,HDJ,HJ,HZJ,KZJ,LJ,PZJ,RJ7# · catalogue 781330 · United States

Discontinued model Data version 2014-05
Parts groups Model variants Characteristics Frame ranges Catalogue groups Illustration notes Newest parts Spec codes

Heating & Air Conditioning - Vacuum Piping

5 part groups · 5 illustrations

Illustrations

Figure 872821A 872821A 1990-01 → — Figure 873511D 873511D 1990-01 → 1993-05 Figure 873511D 873511D 1990-01 → 2002-07 Figure 872822 872822 1993-05 → — Figure 879156 879156 1999-08 → 2007-01

Part groups

PNCDescription
88031 Actuator Set, Idle-up
88645A Union (FOR IDLE UP DEVICE)
88645B Joint, NO.1 (FOR IDLE UP DIVICE)
88691 Valve, Magnet (FOR IDLE UP DEVICE)
88691C Hose, Vacuum (FOR IDLE UP DEVICE), NO.1
PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
