Toyota Land Cruiser
2007-01 → present · chassis FZJ7#,GDJ7#,GDJL7#,GRJ7#,HZJ7#,VDJ7#,VDJL7# · catalogue 781370 · United States
Supported model
Data version 2024-10
Dashed callouts are standard fasteners the factory draws but does not list
as separate parts — there is no part number behind them.
| Part number | Description | Fitment | Price | |
|---|---|---|---|---|
| 45025D — Cover Sub-assy, Steering Column Hole, NO.1 | ||||
| 45025-60220 |
Cover Sub-assy, Steering Column Hole, NO.1
2009-07 → 2016-08
ended
|
GRJ7#,HZJ7# LHD | — | |
| 45025-60230 |
Cover Sub-assy, Steering Column Hole, NO.1
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45025-60230 |
Cover Sub-assy, Steering Column Hole, NO.1
2009-07 → 2016-08
ended
|
GRJ79,HZJ7#,VDJ7# RHD | — | |
| 45025-60220 |
Cover Sub-assy, Steering Column Hole, NO.1
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45025-60220 |
Cover Sub-assy, Steering Column Hole, NO.1
2016-08 → 2023-09
ended
|
HZJ76,78,79 LHD GEN;GRJ7#,HZJ71,VDJ7# LHD | — | |
| 45025-60230 |
Cover Sub-assy, Steering Column Hole, NO.1
2016-08 → 2023-09
ended
|
GRJ79,HZJ7#,VDJ7#,L7# RHD (CBU,IV) | — | |
| 45025-60220 |
Cover Sub-assy, Steering Column Hole, NO.1
2023-09 → —
|
GDJ7#,GRJ7#,HZJ7# LHD | — | |
| 45025-60220 |
Cover Sub-assy, Steering Column Hole, NO.1
2023-09 → 2024-09
ended
|
VDJ7# GCC | — | |
| 45025-60230 |
Cover Sub-assy, Steering Column Hole, NO.1
2023-09 → 2024-09
ended
|
VDJL79 STD;VDJ76,L76,L78 RHD | — | |
| 45025-60230 |
Cover Sub-assy, Steering Column Hole, NO.1
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45025-60230 |
Cover Sub-assy, Steering Column Hole, NO.1
2023-09 → —
|
GDJ7#,L7#,GRJ79,HZJ7# RHD | — | |
| 45201B — Ring, Shaft Snap(FOR STEERING MAIN SHAFT) | ||||
| 90520-17042 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 90520-21023 note |
Ring, Shaft Snap(FOR STEERING MAIN SHAFT)
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45203 — Shaft Sub-assy, Steering Intermediate, NO.2 | ||||
| 45203-60190 |
Shaft Sub-assy, Steering Intermediate, NO.2
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45203-60190 |
Shaft Sub-assy, Steering Intermediate, NO.2
2009-07 → 2016-08
ended
|
GRJ79,HZJ7#,VDJ7# RHD | — | |
| 45203-60200 |
Shaft Sub-assy, Steering Intermediate, NO.2
2009-07 → 2016-08
ended
|
GRJ7#,HZJ7# LHD | — | |
| 45203-60190 |
Shaft Sub-assy, Steering Intermediate, NO.2
2016-08 → 2023-09
ended
|
VDJ79,L79 DCB IV;GRJ79,HZJ7#,VDJ7#,L76,L78 RHD +1 | — | |
| 45203-60200 |
Shaft Sub-assy, Steering Intermediate, NO.2
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45203-60200 |
Shaft Sub-assy, Steering Intermediate, NO.2
2016-08 → 2023-09
ended
|
GRJ7#,HZJ71 LHD;HZJ76,78,79 LHD GEN | — | |
| 45203-60250 |
Shaft Sub-assy, Steering Intermediate, NO.2
2016-08 → 2023-09
ended
|
VDJ79,L79 PIC IV | — | |
| 45203-60260 |
Shaft Sub-assy, Steering Intermediate, NO.2
2017-01 → 2023-09
ended
|
VDJ7# GCC | — | |
| 45203-60190 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → 2024-09
ended
|
VDJL79 DCB STD;VDJ76,L76,L78 RHD | — | |
| 45203-60190 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → 2025-08
ended
|
VDJ79 GEN;VDJ79,L79 DCB LX +1 | — | |
| 45203-60190 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → —
|
GRJ79,HZJ79 RHD;GDJ79 RHD PIC +3 | — | |
| 45203-60200 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → —
|
GDJ7#,GRJ7#,HZJ7# LHD | — | |
| 45203-60250 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → 2024-09
ended
|
VDJL79 PIC STD | — | |
| 45203-60250 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → —
|
GDJ79,L79 PIC IV | — | |
| 45203-60250 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → 2025-08
ended
|
VDJ79 STD IV;VDJL79 PIC +1 | — | |
| 45203-60260 |
Shaft Sub-assy, Steering Intermediate, NO.2
2023-09 → 2024-09
ended
|
VDJ7# GCC | — | |
| 45204 — Tube Assy, Steering Column, Lower | ||||
| 45204-22090 |
Tube Assy, Steering Column, Lower
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45204-22090 |
Tube Assy, Steering Column, Lower
2009-07 → 2012-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45204-60040 |
Tube Assy, Steering Column, Lower
2012-08 → 2016-08
ended
|
GRJ7#,HZJ7#,VDJ7# | — | |
| 45204-60040 |
Tube Assy, Steering Column, Lower
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45204-60040 |
Tube Assy, Steering Column, Lower
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45204-60040 |
Tube Assy, Steering Column, Lower
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45204-60040 |
Tube Assy, Steering Column, Lower
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45204-60040 |
Tube Assy, Steering Column, Lower
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45205J — Tube Sub-assy, Steering Column, Upper | ||||
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45870-60050 |
Tube Sub-assy, Steering Column, Upper
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2023-09 → —
|
GDJ76,78,79,L7#,GRJ7#,HZJ7# 5F | — | |
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45205-22260 |
Tube Sub-assy, Steering Column, Upper
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45205-60200 |
Tube Sub-assy, Steering Column, Upper
2023-09 → —
|
GDJ7#,L7#,GRJ7# 6FC | — | |
| 45210 — Shaft Assy, Steering Main | ||||
| 45210-60061 |
Shaft Assy, Steering Main
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45210-60170 |
Shaft Assy, Steering Main
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45219 — Yoke, Steering Sliding | ||||
| 45219-60100 |
Yoke, Steering Sliding
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45219-60100 |
Yoke, Steering Sliding
2009-07 → 2016-08
ended
|
GRJ79,HZJ7#,VDJ7# RHD | — | |
| 45219-60110 |
Yoke, Steering Sliding
2009-07 → 2016-08
ended
|
GRJ7#,HZJ7# LHD | — | |
| 45219-60100 |
Yoke, Steering Sliding
2016-08 → 2023-09
ended
|
GRJ79,HZJ7#,VDJ7#,L7# RHD (CBU,IV) | — | |
| 45219-60110 |
Yoke, Steering Sliding
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45219-60110 |
Yoke, Steering Sliding
2016-08 → 2023-09
ended
|
GRJ7#,HZJ71 LHD;HZJ76,78,79 LHD GEN | — | |
| 45219-60120 |
Yoke, Steering Sliding
2017-01 → 2023-09
ended
|
VDJ7# GCC | — | |
| 45219-60100 |
Yoke, Steering Sliding
2023-09 → 2024-09
ended
|
VDJL79 STD;VDJ76,L76,L78 RHD | — | |
| 45219-60100 |
Yoke, Steering Sliding
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45219-60100 |
Yoke, Steering Sliding
2023-09 → —
|
GDJ7#,L7#,GRJ79,HZJ7# RHD | — | |
| 45219-60110 |
Yoke, Steering Sliding
2023-09 → —
|
GDJ7#,GRJ7#,HZJ7# LHD | — | |
| 45219-60120 |
Yoke, Steering Sliding
2023-09 → 2024-09
ended
|
VDJ7# GCC | — | |
| 45220 — Shaft Assy, Steering Intermediate | ||||
| 45220-60101 |
Shaft Assy, Steering Intermediate
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45220-60290 |
Shaft Assy, Steering Intermediate
2009-07 → 2016-08
ended
|
GRJ79,HZJ7#,VDJ7# RHD | — | |
| 45220-60290 |
Shaft Assy, Steering Intermediate
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45220-60300 |
Shaft Assy, Steering Intermediate
2009-07 → 2016-08
ended
|
GRJ7#,HZJ7# LHD | — | |
| 45220-60300 |
Shaft Assy, Steering Intermediate
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45220-60300 |
Shaft Assy, Steering Intermediate
2016-08 → 2023-09
ended
|
GRJ7#,HZJ71 LHD;HZJ76,78,79 LHD GEN | — | |
| 45220-60310 |
Shaft Assy, Steering Intermediate
2016-08 → 2023-09
ended
|
GRJ79,HZJ7#,VDJ7#,L7# RHD (CBU,IV) | — | |
| 45220-60320 |
Shaft Assy, Steering Intermediate
2017-01 → 2023-09
ended
|
VDJ7# GCC | — | |
| 45220-60300 |
Shaft Assy, Steering Intermediate
2023-09 → —
|
GDJ7#,GRJ7#,HZJ7# LHD | — | |
| 45220-60310 |
Shaft Assy, Steering Intermediate
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45220-60310 |
Shaft Assy, Steering Intermediate
2023-09 → 2024-09
ended
|
VDJL79 STD;VDJ76,L76,L78 RHD | — | |
| 45220-60310 |
Shaft Assy, Steering Intermediate
2023-09 → —
|
GDJ7#,L7#,GRJ79,HZJ7# RHD | — | |
| 45220-60320 |
Shaft Assy, Steering Intermediate
2023-09 → 2024-09
ended
|
VDJ7# GCC | — | |
| 45258 — Bracket, Steering Column Tube | ||||
| 45258-60010 |
Bracket, Steering Column Tube
2012-08 → 2016-08
ended
|
GRJ7#,HZJ7#,VDJ7# | — | |
| 45258-60010 |
Bracket, Steering Column Tube
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45258-60010 |
Bracket, Steering Column Tube
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45258-60010 |
Bracket, Steering Column Tube
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45258-60010 |
Bracket, Steering Column Tube
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45258-60010 |
Bracket, Steering Column Tube
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45259C — Sheet, Steering Main Shaft Bearing | ||||
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45259-35010 |
Sheet, Steering Main Shaft Bearing
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45261 — Spring, Tilt Steering Jump UP | ||||
| 45261-35020 |
Spring, Tilt Steering Jump UP
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45261-35020 |
Spring, Tilt Steering Jump UP
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45261-35020 |
Spring, Tilt Steering Jump UP
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45261-35020 |
Spring, Tilt Steering Jump UP
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45261-35020 |
Spring, Tilt Steering Jump UP
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45261-35020 |
Spring, Tilt Steering Jump UP
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45261-35020 |
Spring, Tilt Steering Jump UP
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45262A — Spring, Tilt Lever Return | ||||
| 45262-35010 |
Spring, Tilt Lever Return
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45262-35010 |
Spring, Tilt Lever Return
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45262-35010 |
Spring, Tilt Lever Return
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45262-35010 |
Spring, Tilt Lever Return
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45262-35010 |
Spring, Tilt Lever Return
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45262-35010 |
Spring, Tilt Lever Return
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45262-35010 |
Spring, Tilt Lever Return
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45263 — Ring, Steering Column, NO.1 | ||||
| 45263-35010 |
Ring, Steering Column, NO.1
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45263-35010 |
Ring, Steering Column, NO.1
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45263-35010 |
Ring, Steering Column, NO.1
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45263-35010 |
Ring, Steering Column, NO.1
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45263-35010 |
Ring, Steering Column, NO.1
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45263-35010 |
Ring, Steering Column, NO.1
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45263-35010 |
Ring, Steering Column, NO.1
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45271 — Clamp, Steering Column, Upper | ||||
| 45271-22020 |
Clamp, Steering Column, Upper
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45271-22020 |
Clamp, Steering Column, Upper
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45271-22020 |
Clamp, Steering Column, Upper
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45271-22020 |
Clamp, Steering Column, Upper
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45271-22020 |
Clamp, Steering Column, Upper
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45271-22020 |
Clamp, Steering Column, Upper
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45271-22020 |
Clamp, Steering Column, Upper
2023-09 → —
|
GDJ76,78,79,L7#,GRJ7#,HZJ7# 5F | — | |
| 45280A — Bracket Assy, Steering Column, Upper | ||||
| 45280-60281 |
Bracket Assy, Steering Column, Upper
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7# GEN | — | |
| 45280-60381 |
Bracket Assy, Steering Column, Upper
2007-01 → 2009-07
ended
|
FZJ71,76,79,HZJ76,78,79,VDJ7# ARL,GCC | — | |
| 45280-60630 |
Bracket Assy, Steering Column, Upper
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45280-60630 |
Bracket Assy, Steering Column, Upper
2009-07 → 2016-08
ended
|
GRJ79,HZJ7# GEN;GRJ71,76,78 LHD GEN | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2010-08 → 2016-08
ended
|
GRJ7# LHD GEN | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2012-08 → 2016-08
ended
|
GRJ7# LHD GEN | — | |
| 45280-60640 |
Bracket Assy, Steering Column, Upper
2009-07 → 2016-08
ended
|
VDJ79;GRJ71,76,79,HZJ76,78,79,VDJ76,78 ARL,GCC | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2009-07 → 2010-08
ended
|
GRJ71,78,79 LHD GEN | — | |
| 45280-60630 |
Bracket Assy, Steering Column, Upper
2016-08 → 2023-09
ended
|
GRJ79 LHD GEN;GRJ71,76,78,HZJ7# GEN | — | |
| 45280-60640 |
Bracket Assy, Steering Column, Upper
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45280-60640 |
Bracket Assy, Steering Column, Upper
2016-08 → 2023-09
ended
|
GRJ79 RHD;VDJ76,79 CBU,IV;GRJ7#,VDJ78,L7# ARL,GCC | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2016-08 → 2023-09
ended
|
GRJ7# LHD (DCB,HT,PIC) GEN | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2016-08 → 2023-09
ended
|
GRJ7# LHD (DCB,HT,PIC) GEN | — | |
| 45280-52100 |
Bracket Assy, Steering Column, Upper
2023-09 → —
|
GDJ7#,L7#,GRJ7# 6FC | — | |
| 45280-60630 |
Bracket Assy, Steering Column, Upper
2023-09 → —
|
GRJ79 LHD GEN;GRJ71,76,78,HZJ7# GEN | — | |
| 45280-60640 |
Bracket Assy, Steering Column, Upper
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2023-09 → —
|
GRJ76,79 LHD GEN CBU | — | |
| 45280-60640 |
Bracket Assy, Steering Column, Upper
2023-09 → —
|
GRJ79 RHD;GRJ7# 5F GCC;GDJ76,78,79,L7# +1 | — | |
| 45280-60640 note |
Bracket Assy, Steering Column, Upper
2023-09 → 2024-10
ended
|
GRJ79 IV;GRJ78,79 LHD (DCB,HT) +1 | — | |
| 45280-60640 |
Bracket Assy, Steering Column, Upper
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45286B — Cover, Steering Column, Upr | ||||
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2016-08 → 2021-07
ended
|
HZJ79 79,HZJ71,78,VDJ76 IV;GRJ78,VDJ78;GRJ79,VDJ79 (DCB,HT,SOT) +6 | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
VDJ78;HZJ79 1,76,79,HZJ71,78,VDJ76 IV;GRJ78,HZJ76,79 (DCB,HT,SOT) +6 | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
VDJ79 DCB,HT) DCB;HZJ76,79 (ARL,GCC) +6 | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2016-08 → 2023-09
ended
|
VDJL7# | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2016-08 → 2021-07
ended
|
VDJ79 76 DCB;HZJ76,79 (DCB,HT) +7 | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2022-09 → 2023-09
ended
|
VDJL79 DCB;VDJL76,79 LX | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
VDJ79 LX IV | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
GRJ79 ,VDJ76 LX;VDJ79 (DCB,HT) +8 | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
GRJ71,HZJ71,VDJ79 (PIC,SOT) STD (CBU,IV) | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
VDJ78;HZJ79 6,78,79,HZJ71,78 IV;GRJ79,VDJ76 (HT,PIC) +6 | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
VDJ78;HZJ79 6,78,79,HZJ71,78 IV;GRJ79,VDJ76 (HT,PIC) +6 | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2021-07 → 2023-09
ended
|
VDJ79 DCB,HT) DCB;HZJ76,79 (ARL,GCC) +6 | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2016-08 → 2021-07
ended
|
VDJ79 LX;VDJ79 DCB;HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ76,78 +1 | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45286-22510-E0 note |
Cover, Steering Column, Upr
2016-08 → 2023-09
ended
|
VDJL7# DCB,HT;VDJ79 PIC STD +1 | — | |
| 45286-22510-B0 note |
Cover, Steering Column, Upr
2023-09 → —
|
GRJ71,HZJ71 SOT | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → —
|
GDJ76,79,L76,L79 6FC LX ARL | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → —
|
GDJL78 7#,HZJ71,78,79 6FC;GDJ76 (DCB,HT,PIC) +10 | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → —
|
HZJ76;GDJ79 71,76,79 DCB LX +9 | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → —
|
GDJL76,78 5F;GDJL79 5F LX;GDJ79,L76,L79 +2 | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → 2025-08
ended
|
VDJ79 IV;VDJL79 LX | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → 2025-08
ended
|
VDJ79 STD GEN | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → 2025-08
ended
|
VDJ79 LX GEN | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → 2024-09
ended
|
VDJ78,L78;VDJ79 STD GCC | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → 2024-09
ended
|
VDJL76;VDJL79 STD | — | |
| 45286-22510-C0 note |
Cover, Steering Column, Upr
2023-09 → 2024-09
ended
|
VDJ76;VDJ79 LX GCC | — | |
| 45287 — Cover, Steering Column, Lwr | ||||
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2009-07 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
VDJ78;HZJ79 1,76,79,HZJ71,78,VDJ76 IV;GRJ78,HZJ76,79 (DCB,HT,SOT) +6 | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
VDJ79 DCB,HT) DCB;HZJ76,79 (ARL,GCC) +6 | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2016-08 → 2023-09
ended
|
VDJL7# | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2016-08 → 2021-07
ended
|
HZJ79 79,HZJ71,78,VDJ76 IV;GRJ78,VDJ78;GRJ79,VDJ79 (DCB,HT,SOT) +6 | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2016-08 → 2021-07
ended
|
VDJ79 76 DCB;HZJ76,79 (DCB,HT) +7 | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2022-09 → 2023-09
ended
|
VDJL79 DCB;VDJL76,79 LX | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
VDJ79 LX IV | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
GRJ79 ,VDJ76 LX;VDJ79 (DCB,HT) +8 | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
GRJ71,HZJ71,VDJ79 (PIC,SOT) STD (CBU,IV) | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
VDJ78;HZJ79 6,78,79,HZJ71,78 IV;GRJ79,VDJ76 (HT,PIC) +6 | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2016-08 → 2021-07
ended
|
VDJ79 LX;VDJ79 DCB;HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ76,78 +1 | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
VDJ78;HZJ79 6,78,79,HZJ71,78 IV;GRJ79,VDJ76 (HT,PIC) +6 | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2021-07 → 2023-09
ended
|
VDJ79 DCB,HT) DCB;HZJ76,79 (ARL,GCC) +6 | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45287-60570-E0 note |
Cover, Steering Column, Lwr
2016-08 → 2023-09
ended
|
VDJL7# DCB,HT;VDJ79 PIC STD +1 | — | |
| 45287-60570-B0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
GRJ71,HZJ71 SOT | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → 2024-09
ended
|
VDJ76;VDJ79 LX GCC | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → 2024-09
ended
|
VDJL76;VDJL79 STD | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → 2024-09
ended
|
VDJ78,L78;VDJ79 STD GCC | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → 2025-08
ended
|
VDJ79 LX GEN | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → 2025-08
ended
|
VDJ79 STD GEN | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → 2025-08
ended
|
VDJ79 IV;VDJL79 LX | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
HZJ76;GRJ79 5F LX;GDJ76,79,GRJ71,76 (DCB,HT) +3 | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
GDJ76 D 5F (GCC,GEN) +7 | — | |
| 45287-60570-C0 note |
Cover, Steering Column, Lwr
2024-10 → —
|
GDJ79,L7# 5F ARL | — | |
| 45287-60650-C0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
GDJ76,79,L76,L79 6FC LX ARL | — | |
| 45287-60650-C0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
GDJ78,L78,GRJ78 6FC;GDJ71,76 LHD 6FC +4 | — | |
| 45287-60650-C0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
GDJ71,76 RHD 6FC GEN;GDJ71,76,79,GRJ71,76,79 +3 | — | |
| 45287-60650-C0 note |
Cover, Steering Column, Lwr
2023-09 → —
|
GDJ79,L76,L79 6FC STD ARL | — | |
| 45635 — Support, Intermediate Link Joint Protector | ||||
| 45635-60050 |
Support, Intermediate Link Joint Protector
2007-01 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45635-60050 |
Support, Intermediate Link Joint Protector
2007-01 → 2016-08
ended
|
GRJ79,HZJ7#,VDJ7# RHD | — | |
| 45635-60050 |
Support, Intermediate Link Joint Protector
2007-01 → 2009-07
ended
|
FZJ71,78,79 RHD | — | |
| 45635-60060 |
Support, Intermediate Link Joint Protector
2007-01 → 2009-07
ended
|
FZJ7# LHD | — | |
| 45635-60060 |
Support, Intermediate Link Joint Protector
2007-01 → 2016-08
ended
|
GRJ7#,HZJ7# LHD | — | |
| 45635-60050 |
Support, Intermediate Link Joint Protector
2016-08 → 2023-09
ended
|
VDJ79,L79 DCB IV;GRJ79,HZJ7#,VDJ7#,L76,L78 RHD +1 | — | |
| 45635-60060 |
Support, Intermediate Link Joint Protector
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45635-60060 |
Support, Intermediate Link Joint Protector
2016-08 → 2017-01
ended
|
GRJ7#,HZJ71 LHD;HZJ76,78,79 LHD GEN | — | |
| 45635-60061 |
Support, Intermediate Link Joint Protector
2017-01 → 2023-09
ended
|
GRJ7#,HZJ7#,VDJ7# LHD | — | |
| 45635-60090 |
Support, Intermediate Link Joint Protector
2016-08 → 2023-09
ended
|
VDJ79,L79 PIC IV | — | |
| 45635-60050 |
Support, Intermediate Link Joint Protector
2023-09 → 2024-09
ended
|
VDJL79 DCB STD;VDJ76,L76,L78 RHD | — | |
| 45635-60050 |
Support, Intermediate Link Joint Protector
2023-09 → 2025-08
ended
|
VDJ79 GEN;VDJ79,L79 DCB LX +1 | — | |
| 45635-60050 |
Support, Intermediate Link Joint Protector
2023-09 → —
|
GRJ79,HZJ79 RHD;GDJ79 RHD PIC +3 | — | |
| 45635-60061 |
Support, Intermediate Link Joint Protector
2023-09 → 2024-09
ended
|
VDJ7# GCC | — | |
| 45635-60061 |
Support, Intermediate Link Joint Protector
2023-09 → —
|
GDJ7#,GRJ7#,HZJ7# LHD | — | |
| 45635-60090 |
Support, Intermediate Link Joint Protector
2023-09 → 2024-09
ended
|
VDJL79 PIC STD | — | |
| 45635-60090 |
Support, Intermediate Link Joint Protector
2023-09 → 2025-08
ended
|
VDJ79 STD IV;VDJL79 PIC +1 | — | |
| 45635-60090 |
Support, Intermediate Link Joint Protector
2023-09 → —
|
GDJ79,L79 PIC IV | — | |
| 45636B — Protector, Intermediate Link Joint | ||||
| 45636-60051 |
Protector, Intermediate Link Joint
2007-01 → 2012-08
ended
|
GRJ71,78 RHD | — | |
| 45636-60051 |
Protector, Intermediate Link Joint
2007-01 → 2016-08
ended
|
GRJ79,HZJ7#,VDJ7# RHD | — | |
| 45636-60051 |
Protector, Intermediate Link Joint
2007-01 → 2009-07
ended
|
FZJ71,78,79 RHD | — | |
| 45636-60061 |
Protector, Intermediate Link Joint
2007-01 → 2009-07
ended
|
FZJ7# LHD | — | |
| 45636-60061 |
Protector, Intermediate Link Joint
2007-01 → 2016-08
ended
|
GRJ7#,HZJ7# LHD | — | |
| 45636-60051 |
Protector, Intermediate Link Joint
2016-08 → 2023-09
ended
|
VDJ79,L79 DCB IV;GRJ79,HZJ7#,VDJ7#,L76,L78 RHD +1 | — | |
| 45636-60061 |
Protector, Intermediate Link Joint
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45636-60061 |
Protector, Intermediate Link Joint
2016-08 → 2017-01
ended
|
GRJ7#,HZJ71 LHD;HZJ76,78,79 LHD GEN | — | |
| 45636-60062 |
Protector, Intermediate Link Joint
2017-01 → 2023-09
ended
|
GRJ7#,HZJ7#,VDJ7# LHD | — | |
| 45636-60130 |
Protector, Intermediate Link Joint
2016-08 → 2023-09
ended
|
VDJ79,L79 PIC IV | — | |
| 45636-60051 |
Protector, Intermediate Link Joint
2023-09 → 2024-09
ended
|
VDJL79 DCB STD;VDJ76,L76,L78 RHD | — | |
| 45636-60051 |
Protector, Intermediate Link Joint
2023-09 → 2025-08
ended
|
VDJ79 GEN;VDJ79,L79 DCB LX +1 | — | |
| 45636-60051 |
Protector, Intermediate Link Joint
2023-09 → —
|
GRJ79,HZJ79 RHD;GDJ79 RHD PIC +3 | — | |
| 45636-60062 |
Protector, Intermediate Link Joint
2023-09 → 2024-09
ended
|
VDJ7# GCC | — | |
| 45636-60062 |
Protector, Intermediate Link Joint
2023-09 → —
|
GDJ7#,GRJ7#,HZJ7# LHD | — | |
| 45636-60130 |
Protector, Intermediate Link Joint
2023-09 → —
|
GDJ79,L79 PIC IV | — | |
| 45636-60130 |
Protector, Intermediate Link Joint
2023-09 → 2025-08
ended
|
VDJ79 STD IV;VDJL79 PIC +1 | — | |
| 45636-60130 |
Protector, Intermediate Link Joint
2023-09 → 2024-09
ended
|
VDJL79 PIC STD | — | |
| 45765 — Guide, Telescopic Steering | ||||
| 45765-35010 |
Guide, Telescopic Steering
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45765-35010 |
Guide, Telescopic Steering
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45765-35010 |
Guide, Telescopic Steering
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45765-35010 |
Guide, Telescopic Steering
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45765-35010 |
Guide, Telescopic Steering
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45765-35010 |
Guide, Telescopic Steering
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45765-35010 |
Guide, Telescopic Steering
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45804J — Collar Sub-assy, Break Away | ||||
| 45804-22030 |
Collar Sub-assy, Break Away
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45804-22030 |
Collar Sub-assy, Break Away
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45804-22030 |
Collar Sub-assy, Break Away
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45804-22030 |
Collar Sub-assy, Break Away
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45804-22030 |
Collar Sub-assy, Break Away
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45804-22030 |
Collar Sub-assy, Break Away
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45804-22030 |
Collar Sub-assy, Break Away
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45813 — Collar, Tilt Steering Support, NO.1 | ||||
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45813-22010 note |
Collar, Tilt Steering Support, NO.1
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45813-22020 note |
Collar, Tilt Steering Support, NO.1
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45813-22030 note |
Collar, Tilt Steering Support, NO.1
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45813-22040 note |
Collar, Tilt Steering Support, NO.1
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45813-22050 note |
Collar, Tilt Steering Support, NO.1
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45813-12020 note |
Collar, Tilt Steering Support, NO.1
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45821B — Reinforce, Tilt Steering Support, NO.1 | ||||
| 45821-22010 |
Reinforce, Tilt Steering Support, NO.1
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45821-35020 |
Reinforce, Tilt Steering Support, NO.1
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45826 — Lever, Steering Tilt | ||||
| 45826-22130 |
Lever, Steering Tilt
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45826-22130 |
Lever, Steering Tilt
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45826-22130 |
Lever, Steering Tilt
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45826-22130 |
Lever, Steering Tilt
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45826-22130 |
Lever, Steering Tilt
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45826-22130 |
Lever, Steering Tilt
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45826-22130 |
Lever, Steering Tilt
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45831 — Bolt, Tilt Lever Lock, NO.1 | ||||
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45831-35010 |
Bolt, Tilt Lever Lock, NO.1
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45832 — Cable, Tilt Steering Support Bond | ||||
| 45832-60020 |
Cable, Tilt Steering Support Bond
2012-08 → 2016-08
ended
|
GRJ7#,HZJ7#,VDJ7# | — | |
| 45832-60020 |
Cable, Tilt Steering Support Bond
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45832-60020 |
Cable, Tilt Steering Support Bond
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45832-60020 |
Cable, Tilt Steering Support Bond
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45832-60020 |
Cable, Tilt Steering Support Bond
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45832-60020 |
Cable, Tilt Steering Support Bond
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45833 — Nut, Tilt Steering Adjusting, NO.1 | ||||
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45833-20030 |
Nut, Tilt Steering Adjusting, NO.1
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45873 — Stopper, Steering Column Tube | ||||
| 45873-20050 note |
Stopper, Steering Column Tube
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45873-20050 note |
Stopper, Steering Column Tube
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45873-20050 note |
Stopper, Steering Column Tube
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45873-20050 note |
Stopper, Steering Column Tube
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45873-20050 note |
Stopper, Steering Column Tube
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45873-20050 note |
Stopper, Steering Column Tube
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45873-20050 note |
Stopper, Steering Column Tube
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45873-35010 note |
Stopper, Steering Column Tube
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45877A — Spacer, Steering Column Bracket | ||||
| 45877-35030 |
Spacer, Steering Column Bracket
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45877-35030 |
Spacer, Steering Column Bracket
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45877-35030 |
Spacer, Steering Column Bracket
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45877-35030 |
Spacer, Steering Column Bracket
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45877-35030 |
Spacer, Steering Column Bracket
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45877-35030 |
Spacer, Steering Column Bracket
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45877-35030 |
Spacer, Steering Column Bracket
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45878A — Bracket, Break Away | ||||
| 45878-35160 |
Bracket, Break Away
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45878-35160 |
Bracket, Break Away
2009-07 → 2012-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45878-35161 |
Bracket, Break Away
2012-08 → 2016-08
ended
|
GRJ7#,HZJ7#,VDJ7# | — | |
| 45878-35161 |
Bracket, Break Away
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45878-35161 |
Bracket, Break Away
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45878-35161 |
Bracket, Break Away
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45878-35161 |
Bracket, Break Away
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45878-35161 |
Bracket, Break Away
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45879A — Capsule, Break Away | ||||
| 45879-22070 |
Capsule, Break Away
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45879-22070 |
Capsule, Break Away
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45879-22070 |
Capsule, Break Away
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45879-22070 |
Capsule, Break Away
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45879-22070 |
Capsule, Break Away
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45879-22070 |
Capsule, Break Away
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45879-22070 |
Capsule, Break Away
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45880A — Bolt(FOR STEERING TILT LEVER) | ||||
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45832-12010 |
Bolt(FOR STEERING TILT LEVER)
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45890A — Pawl Assy, Tilt Steering | ||||
| 45823-35020 |
Pawl Assy, Tilt Steering
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45823-35020 |
Pawl Assy, Tilt Steering
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45890-22050 |
Pawl Assy, Tilt Steering
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45823-35020 |
Pawl Assy, Tilt Steering
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45823-35020 |
Pawl Assy, Tilt Steering
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45823-35020 |
Pawl Assy, Tilt Steering
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45823-35020 |
Pawl Assy, Tilt Steering
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45823-35020 |
Pawl Assy, Tilt Steering
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
| 45897 — Bolt, Steering Lock Set | ||||
| 45897-12020 |
Bolt, Steering Lock Set
2009-07 → 2016-08
ended
|
GRJ71,76,78 LHD;GRJ79,HZJ7#,VDJ7# | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2009-07 → 2012-06
ended
|
GRJ71,78 RHD | — | |
| 45897-12030 |
Bolt, Steering Lock Set
2007-01 → 2009-07
ended
|
FZJ7#,HZJ7#,VDJ7# | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45897-12030 note |
Bolt, Steering Lock Set
2016-08 → 2016-12
ended
|
HZJ76,78,79 GCC | — | |
| 45897-12030 note |
Bolt, Steering Lock Set
2016-08 → 2023-09
ended
|
HZJ76,78,79 GEN;GRJ7#,HZJ71,VDJ7#,L7# CBU,IV | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2023-09 → —
|
GDJ7#,L7#,GRJ7# 6FC | — | |
| 45897-12020 |
Bolt, Steering Lock Set
2023-09 → —
|
GDJ76,78,79,L7#,GRJ7#,HZJ7# 5F | — | |
| 45897-12030 note |
Bolt, Steering Lock Set
2023-09 → 2024-09
ended
|
VDJ79 GCC;VDJL79 STD;VDJ76,78,L76,L78 | — | |
| 45897-12030 note |
Bolt, Steering Lock Set
2023-09 → 2025-08
ended
|
VDJ79 RHD;VDJL79 LX | — | |
| 45897-12030 note |
Bolt, Steering Lock Set
2023-09 → —
|
GDJ7#,L7#,GRJ7#,HZJ7# | — | |
No quantity column: the factory catalogue records which parts a vehicle
takes, never how many.
