Toyota Land Cruiser
2007-01 → present · chassis FZJ7#,GDJ7#,GDJL7#,GRJ7#,HZJ7#,VDJ7#,VDJL7# · catalogue 781370 · United States
Supported model
Data version 2024-10
Front Bumper & Bumper Stay
38 part groups · 9 illustrations
Part groups
| PNC | Description |
|---|---|
| 52015B | Bracket Sub-assy, Front Bumper, RH |
| 52016B | Bracket Sub-assy, Front Bumper, LH |
| 52049 | Cover Sub-assy, Front Bumper Winch |
| 52101B | Plate Sub-assy, Front Bumper Reinforcement |
| 52112C | Extension, Front Bumper |
| 52112D | Extension, Front Bumper, RH |
| 52112K | Extension, Front Bumper, NO.2 |
| 52113D | Extension, Front Bumper, LH |
| 52116B | Retainer, Front Bumper |
| 52119A | Cover, Front Bumper |
| 52125D | Bracket, Fog Lamp Mounting, RH |
| 52126D | Bracket, Fog Lamp Mounting, LH |
| 52127D | Cover, Front Bumper Hole, RH |
| 52128B | Cover, Front Bumper Hole, LH |
| 52130 | Bracket Assy, Front Bumper Side Mounting, RH |
| 52133F | Bracket, Front Bumper, RH |
| 52134G | Bracket, Front Bumper, LH |
| 52137B | Plate, Front Bumper Bracket, NO.1 |
| 52137F | Bracket, Front Bumper Arm Mounting, NO.3 |
| 52138D | Bracket, Front Bumper Arm Mounting, NO.4 |
| 52139D | Plate, Front Bumper Bracket, NO.3 |
| 52140 | Bracket Assy, Front Bumper Side Mounting, LH |
| 52149 | Bracket, Front Bumper, Inner |
| 52149G | Bracket, Front Bumper, Inner RH |
| 52149H | Bracket, Front Bumper, Inner LH |
| 52161C | Piece, Front Bumper |
| 52161T | Piece, Front Bumper |
| 52421A | Pad, Front Bumper |
| 52541C | Protector, Front Bumper, NO.1 |
| 52542A | Protector, Front Bumper, NO.2 |
| 52711A | Garnish, Front Bumper |
| 53285M | Seal, Radiator Side Air, RH |
| 53286D | Seal, Radiator Side Air, LH |
| 75392 | Retainer, Outside Moulding |
| 75392K | Retainer, Outside Moulding, NO.2 |
| 76854B | Retainer, Front Spoiler,NO.2 |
| 81481E | Cover, Fog Lamp, RH |
| 81482C | Cover, Fog Lamp, LH |
PNC is the six-character part-group number the factory catalogue files
parts under. Every part on a drawing belongs to one.
