Toyota Lexus GX470

2002-11 → 2009-08 · chassis UZJ120 · catalogue 781450 · United States

Supported model Data version 2010-01

Front Floor Panel & Front Floor Member

41 part groups · 2 illustrations

PNC	Description
51759A	Cover, Side Door Step Plate, Rear LH
51771E	Plate, Step, RH
51772D	Plate, Step, LH
51773B	Cover, Side Door Step Plate, Front RH
51774A	Cover, Side Door Step Plate, Front LH
51777D	Arm, Front Step, RH
51778H	Stay, Step Plate, LH
51779A	Cover, Side Door Step Plate, Rear RH
51781	Panel, Step, RH
51782	Panel, Step, LH
51787B	Reinforcement, Step Cover
51787C	Insert, Side Door Step Plate
51788A	Reinforcement, Step Cover, LH
51793A	Bracket, Side Step, NO.1 RH
51793B	Bracket, Side Step, NO.1, LH
51795A	Bracket, Side Step, NO.2 RH
51796	Bracket, Side Step, NO.2 LH
51797A	Bracket, Side Step, NO.3
52161P	Piece, Rear Bumper
57051	Member Sub-assy, Front Floor Cross, RH
57052	Member Sub-assy, Front Floor Cross, LH
57401C	Member Sub-assy, Floor Side, Inner RH
57402C	Member Sub-assy, Floor Side, Inner LH
57417	Reinforcement, Front Floor Under, RH
57418	Reinforcement, Front Floor Under, LH
57461B	Member Sub-assy, Center Floor Cross, NO.1
57509	Reinforcement Sub-assy, Front Floor, Center
58111	Pan, Front Floor
58111B	Bolt, Weld(FOR FRONT FLOOR PAN)
58115A	Reinforcement, Front Floor Panel
58127A	Reinforce, Front Cross TO Front Panel Member, RH
58128A	Reinforcement, Front Cross TO Front Panel Member, LH
58171	Reinforcement, Parking Brake Base
58179C	Bracket, Clamp Floor
58191	Footrest, Front Floor
58198	Clip, Footrest
58280A	Boot Assy, Shift Lever
75867D	Clip, Rocker Panel Moulding
81380P	Lamp Assy, Step
81380Q	Lamp Assy, Step
81380R	Bulb, Step Lamp

PNC is the six-character part-group number the factory catalogue files parts under. Every part on a drawing belongs to one.
